Allen-Bradley 2711T-JBIP65DC1 PanelView Junction Box

Product Overview

The Allen-Bradley 2711T-JBIP65DC1 is a MobileView IP65 Junction Box (Smart Junction Box) used in PanelView MobileView / tethered HMI systems.

It acts as the fixed interface between the machine wiring and the portable MobileView terminal, providing power distribution, communication pass-through, and safety interface functions.

Key Specifications (verified)

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2711T-JBIP65DC1
• Product Type: MobileView IP65 Junction Box
• Power Supply: 24 VDC
• Protection Rating: IP65 (dust-tight, water jet protected)
• Series: MobileView accessory system
• Connector Type: Cord glands / industrial sealed wiring entry
• Compatible System: MobileView handheld HMI terminals (e.g., 2711T series)
• Function: Power + communication + safety interface hub

What It Does (Simple Explanation)

This junction box is the fixed docking point of the MobileView system:

1. Machine wiring (24V power + Ethernet/safety signals) connects into the box
2. The box distributes signals safely and in sealed IP65 environment
3. Operator connects handheld HMI via tether cable
4. HMI gets:
   • communication to PLC
   • system power (depending setup)
   • safety enable signals

Key Features

• IP65 rugged industrial enclosure (machine-mounted)
• Designed for MobileView tethered HMI systems
• Cord gland sealed cable entry (industrial wiring protection)
• Supports safety integration (E-Stop / enable signals depending system design)
• Simplifies mobile HMI connection on machines

Advantages

• Reduces wear on PLC/HMI internal ports
• Easy plug-and-play operator station setup
• Strong environmental protection (dust + water jet resistant)
• Centralized wiring point (cleaner machine design)
• Supports mobile operator control systems

Applications

• Large automation machines
• Packaging equipment
• Automotive production lines
• Assembly systems
• Robotics cells
• Machines requiring mobile operator panel (walk-around control)

Important Precautions

•
• Not compatible with standard PanelView Plus terminals (2711P series)
• Incorrect wiring may cause:
  • HMI disconnect
  • safety shutdown (if safety loop included)
  • communication loss
• IP65 means:
  • good protection, but gland sealing must be properly installed
