Allen-Bradley 2711T-B10I1N1 PanelView HMI Terminal

=

Product Overview

The Allen-Bradley 2711T-B10I1N1 is a MobileView (PanelView Mobile HMI) tethered operator terminal designed for portable machine control and monitoring.

It is a high-end industrial Windows-based HMI, used with a tether cable system (like your 2711T cable assembly) to operate machines safely from different positions.

Key Specifications (verified)

• Brand: Allen-Bradley (Rockwell Automation)
• Series: MobileView / PanelView Tethered HMI
• Model: 2711T-B10I1N1
• Display: 10-inch color touchscreen
• CPU: Intel Atom processor (~1.46 GHz class)
• RAM: 4 GB
• Storage: 32 GB
• OS: Windows Embedded Standard (industrial edition)
• Power Supply: 19.2–30 VDC
• Ethernet: 10/100/1000 Mbps
• Safety Features:
  • Illuminated Emergency Stop
  • Enabling switch (depending configuration)
• Protection: Industrial rugged design (machine-floor use)

What It Does (Simple Explanation)

This device is a portable industrial HMI workstation:

1. Operator holds or mounts the MobileView terminal
2. Connects via tether cable (like 2711T-15MCABLE2)
3. Communicates with PLC over Ethernet
4. Runs FactoryTalk View ME / Windows-based HMI application
5. Allows safe machine control from different positions

Key Features

• 10-inch industrial touchscreen display
• Full Windows Embedded platform (not basic HMI firmware)
• High-speed Ethernet communication
• Integrated safety E-Stop (machine safety integration)
• Designed for FactoryTalk View ME applications
• Rugged industrial enclosure

Advantages

• Mobile operation (operator can move around machine)
• Full-feature HMI (more powerful than PanelView Plus 7)
• Strong integration with Rockwell PLC systems
• Safety-ready design (E-Stop + enabling switch)
• Good for large machinery and complex production lines

Applications

• Large automation machines
• Automotive production lines
• Packaging systems
• Assembly systems
• CNC/robotic cells
• Maintenance and diagnostic mobile control stations
