Allen-Bradley 2711T-JBIP65DM1 PanelView / MobileView Junction Box

Product Overview

The Allen-Bradley 2711T-JBIP65DM1 is a MobileView IP65 Junction Box used in the PanelView MobileView (tethered HMI system).

It is a machine-mounted connection hub that provides the interface between:

• MobileView handheld HMI terminal
• machine wiring (power + Ethernet + safety signals)
• tether cable system

Key Specifications (verified)

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2711T-JBIP65DM1
• Series: MobileView / PanelView Tethered System
• Type: IP65 Junction Box (On-machine)
• Power Supply: 24 VDC
• Protection Rating: IP65 dust-tight / water jet protected
• Connector Type: M12 industrial connectors / cord gland interface
• Function: Power + communication + safety interface hub for MobileView system
• Compatibility: MobileView terminals such as 2711T-B10I1N1 series
• Application Type: On-machine installation

What It Does (Simple Explanation)

This junction box is the fixed connection point of the MobileView system:

1. Machine wiring (24V + Ethernet/safety signals) enters the box
2. The box distributes signals in a sealed IP65 environment
3. Operator connects handheld HMI via tether cable
4. HMI communicates with PLC through this interface

Key Features

• IP65 industrial protection (dust + water resistant)
• Designed for MobileView tethered HMI systems
• M12 / sealed industrial connectors
• Centralized wiring interface for machine HMI
• Supports mobile operator control systems
• Reduces strain on PLC/HMI ports

Advantages

• Cleaner machine wiring design
• Faster plug-and-play operator connection
• Better durability vs direct HMI wiring
• Suitable for harsh industrial environments
• Supports mobile control operations

Applications

• Large automation machines
• Packaging production lines
• Automotive manufacturing systems
• Robotics workstations
• Assembly and testing equipment
• Machines requiring portable HMI control
