Allen-Bradley 2711P-K6M20D8 PanelView Plus 6 HMI Terminal





Product Overview

The Allen-Bradley 2711P-K6M20D8 is a PanelView Plus 6 600 operator terminal (HMI) designed to provide a reliable human-machine interface for industrial automation systems. It allows operators to monitor process data, view alarms, and control equipment through FactoryTalk View Machine Edition applications.

Key Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Series: PanelView Plus 6 Standard
• Model: 2711P-K6M20D8
• Product Type: Human Machine Interface (HMI)
• Display Size: 5.7-inch TFT grayscale LCD
• Resolution: 320 × 240 pixels
• Operator Input: Keypad (numeric, navigation, and F1–F10 function keys)
• Power Supply: 18–30 VDC (24 VDC nominal)
• Communication Ports:
  • 10/100 Mbps Ethernet
  • RS-232 serial
  • 1 × USB Host
  • 1 × USB Device
• Memory: 256 MB RAM, 512 MB nonvolatile memory (approximately 73 MB user memory available)
• Operating System: Windows CE 6.0
• Software: FactoryTalk View Machine Edition Runtime
• Front Protection: NEMA Type 4X/12/13, IP66
• Mounting: Panel mount
• Country of Origin: United States

What It Does (Simple Explanation)

The PanelView Plus 6 provides an interface between operators and the PLC.

Typical operation:

1. Displays machine status and production information.
2. Allows operators to start, stop, and adjust machine parameters.
3. Shows alarms and diagnostic messages.
4. Communicates with the PLC through Ethernet or RS-232.
5. Supports data logging, recipes, and user security.

This improves machine operation, troubleshooting, and production efficiency.

Key Features

• 5.7-inch grayscale TFT display
• Keypad operation with programmable function keys
• Ethernet and RS-232 communication
• USB host and device ports
• FactoryTalk View Machine Edition support
• Windows CE 6.0 operating system
• SD card support for data storage and firmware updates
• Industrial NEMA 4X/IP66 front enclosure

Advantages

• Reliable operator interface for industrial machinery
• Easy integration with Allen-Bradley PLC systems
• Supports Ethernet network communication
• Rugged industrial design for harsh environments
• Fast application download and maintenance
• Long service life with LED backlight

Applications

• Packaging machinery
• Material handling systems
• Conveyor control
• Water and wastewater plants
• Food and beverage processing
• Automotive manufacturing
• Process automation
• General industrial machine control
