Allen-Bradley 2098-DSD-HV030-SE Ultra 3000 SERCOS Servo Drive





Product Overview

The Allen-Bradley 2098-DSD-HV030-SE is an Ultra 3000 high-voltage digital servo drive with a SERCOS fiber-optic communication interface. It is designed to provide precise control of AC servo motors in high-performance industrial motion control applications.

Note: The Ultra 3000 series was discontinued by Rockwell Automation on December 31, 2022. Existing systems are still widely supported through repair, refurbishment, and replacement channels.

Key Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Series: Ultra 3000
• Model: 2098-DSD-HV030-SE
• Product Type: Digital AC Servo Drive
• Communication: SERCOS fiber-optic interface
• Input Voltage: 230–480 VAC, 3-phase
• Input Frequency: 47–63 Hz
• Continuous Output Power:
  • 1.5 kW @ 230 VAC
  • 3.0 kW @ 460/480 VAC
• Continuous Output Current: 7 A
• Peak Output Current: 14 A
• Nominal Input Current: 4 A
• Auxiliary Power Input: Supported
• Integrated Dynamic Brake: Internal shunt resistor
• Mounting: Panel mount
• Country of Origin: Mexico

What It Does (Simple Explanation)

The servo drive performs the following sequence:

1. Receives motion commands from the PLC or motion controller.
2. Processes the commands using its digital control algorithms.
3. Supplies controlled power to the servo motor.
4. Receives encoder feedback from the motor.
5. Continuously adjusts torque, speed, and position for accurate closed-loop motion control.

This enables highly accurate and repeatable machine movement in demanding automation applications.

Key Features

• High-voltage digital servo drive
• SERCOS real-time fiber-optic communication
• 3 kW output capability
• Closed-loop position, speed, and torque control
• Internal dynamic braking circuit
• Supports multi-axis coordinated motion
• High-speed digital control
• Industrial-grade reliability

Advantages

• Excellent positioning accuracy
• Fast response for demanding motion applications
• Reliable real-time SERCOS communication
• Suitable for continuous industrial operation
• Integrates with Rockwell motion control systems
• Proven Ultra 3000 platform for legacy equipment

Applications

• CNC machinery
• Packaging equipment
• Printing machines
• Robotics
• Material handling systems
• Semiconductor manufacturing
• Automated assembly equipment
• High-speed production lines
