Allen-Bradley 2711P-T10C4D8 PanelView Plus 6 1000 HMI Terminal





Product Overview

The Allen-Bradley 2711P-T10C4D8 is a PanelView Plus 6 1000 operator terminal (HMI) designed for industrial machine monitoring and operator control. It provides a color touchscreen interface for displaying process information, controlling equipment, managing alarms, and communicating with PLC systems through Ethernet or RS-232.

Key Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Series: PanelView Plus 6
• Model: 2711P-T10C4D8
• Product Type: Human Machine Interface (HMI) / Operator Terminal
• Display Size: 10.4 inch color TFT display
• Display Resolution: 640 × 480 pixels
• Display Color: 18-bit color graphics
• Input Type: Analog resistive touchscreen
• Touch Life: Approximately 1 million presses
• Power Supply: 18–32 VDC (24 VDC nominal)
• Memory:
  • 512 MB RAM
  • 512 MB nonvolatile memory
• Communication Ports:
  • Ethernet
  • RS-232
  • USB Host ports
• Software: FactoryTalk View Machine Edition Runtime
• Operating System: Windows CE 6.0
• Front Protection: NEMA 4X / IP65
• Mounting: Panel mount
• Country of Origin: United States

What It Does (Simple Explanation)

The PanelView Plus 6 works as the operator interface between people and automation equipment.

Typical workflow:

1. PLC collects machine data.
2. HMI receives information through Ethernet or RS-232.
3. Operator views:
   • machine status
   • alarms
   • production data
   • parameters
4. Operator sends commands through the touchscreen.
5. PLC executes machine operations.

Key Features

• 10.4-inch large color touchscreen
• High-resolution industrial display
• FactoryTalk View ME compatible
• Ethernet and serial communication
• USB support for data transfer and updates
• Supports alarm displays and recipe management
• Rugged industrial enclosure
• Suitable for continuous factory operation

Advantages

• Large screen improves operator visibility
• Easy integration with Allen-Bradley PLC systems
• Supports complex graphical interfaces
• Reduces machine operation errors
• Provides real-time diagnostics and alarm information
• Suitable for demanding industrial environments

Applications

• Packaging machinery
• Automotive production lines
• Conveyor systems
• CNC equipment
• Process control systems
• Food and beverage automation
• Material handling systems
• Factory automation equipment
