Allen-Bradley 1440-VDRS06-06RH XM Vibration Monitoring Module

Allen-Bradley 1440-VDRS06-06RH XM Vibration Monitoring Module

Product Overview

The Allen-Bradley 1440-VDRS06-06RH is an XM-161 Overall Vibration Monitoring Module from Rockwell Automation’s XM Condition Monitoring product family. It is designed for continuous vibration monitoring of rotating machinery, collecting vibration signals from IEPE accelerometers and providing machine health data for predictive maintenance applications.

This module provides 6 vibration input channels, supports DeviceNet communication, and includes isolated 4–20 mA output channels for integration with PLC, DCS, and monitoring systems.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 1440-VDRS06-06RH
• Product Type:
  • XM-161 Overall Vibration Monitoring Module
  • Condition Monitoring Module
• Series:
  • Bulletin 1440 XM

Vibration Input

• Number of Channels:
  • 6 channels
• Sensor Type:
  • IEPE accelerometers
• Signal Type:
  • AC coupled vibration signals
• Sensor Excitation:
  • IEPE constant current approximately 2.69 mA ±20%
• Input:
  • Direct vibration input
• Measurement:
  • Overall vibration level monitoring

Communication & Output

• Communication Interface:
  • DeviceNet
• Analog Outputs:
  • 6 × 4–20 mA outputs
• Output Configuration:
  • Two isolated banks of three outputs
  • One output per vibration channel

Power Supply

• Supply Voltage:
  • 24 VDC typical industrial power supply
• Mounting:
  • DIN rail mounting
• Application:
  • Industrial condition monitoring systems

Advantages & Features

• Real-time monitoring of machine vibration condition
• Supports predictive maintenance strategies
• Detects abnormal vibration caused by bearing wear, imbalance, misalignment, and mechanical faults
• Six-channel vibration monitoring capability
• Supports IEPE vibration sensors directly
• DeviceNet communication for PLC integration
• 4–20 mA outputs allow connection to DCS and control systems
• Helps reduce unexpected equipment downtime
• Designed for continuous industrial operation

Applications

• Motor condition monitoring
• Pump vibration monitoring
• Fan and blower monitoring
• Compressor monitoring
• Turbine and rotating equipment protection
• Factory predictive maintenance systems
• Process industry equipment monitoring
• Machine health management

Compatible Devices

Commonly connected equipment:

• IEPE accelerometers
• Industrial vibration sensors
• Motor bearing monitoring systems
• Rotating machinery diagnostic equipment

Important Notes

• 1440-VDRS06-06RH has been discontinued by Rockwell Automation. Existing systems may require replacement with alternative condition monitoring solutions or refurbished units.
• Verify DeviceNet network compatibility before replacement.
• Confirm vibration sensor type before installation.
• Ensure correct 24VDC power supply.
• Configure module parameters using compatible XM configuration software.
