Product Overview

The Allen-Bradley 800H-FRXT6A1 is a 30 mm industrial push-pull operator device from Rockwell Automation Bulletin 800H series. Although often listed as a selector switch, this model is actually a maintained push-pull / twist-to-release control switch with a red mushroom head, commonly used for industrial machine control and operator panels.

It provides a maintained ON/OFF control function and is suitable for applications requiring a push-to-actuate and twist-to-reset operation.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 800H-FRXT6A1
• Product Type:
  • 30 mm Push-Pull Control Device
  • Mushroom Head Operator Switch
• Series:
  • Bulletin 800H

Operator Details

• Operator Type:
  • Standard Mushroom Head
• Button Color:
  • Red
• Button Size:
  • 40 mm
• Operation:
  • Push-Pull / Twist Release
• Function:
  • Maintained 2-position operation
• Illumination:
  • Non-illuminated
• Mounting Hole:
  • 30.5 mm

Contact Specifications

• Contact Configuration:
  • 1NC + 1NO
• Contact Type:
  • Snap action
• Thermal Current Rating:
  • 10 A
• AC Utilization:
  • A600 (AC-15)
• DC Utilization:
  • Q600 (DC-13)
• Maximum Operating Voltage:
  • 600 VAC / 600 VDC
• Connection:
  • Screw terminal
• Wire Range:
  • 14–18 AWG

Mechanical & Environmental

• Enclosure Rating Compatibility:
  • NEMA 1, 4, 4X, 12, 13
• Mechanical Life:
  • Minimum 250,000 operations
• Electrical Life:
  • Up to 1,000,000 operations at rated load
• Operating Temperature:
  • Up to -25°C minimum operating condition
• Vibration Resistance:
  • Up to 10 G

Advantages & Features

• Heavy-duty industrial construction for harsh environments
• Large 40 mm mushroom actuator for easy operation
• Push-pull maintained control design
• Twist-to-release reset function improves operator control
• 1NO + 1NC contacts provide flexible wiring options
• High mechanical durability and long service life
• Compatible with Allen-Bradley 800H industrial control stations
• Suitable for machine operator interfaces

Applications

• Industrial control panels
• Machine start/stop circuits
• Motor control systems
• Production line equipment
• Automation machinery
• Safety-related operator stations
• Factory equipment control

Important Notes

• This model is not a rotary selector switch; it is a push-pull/twist-release operator device.
• Confirm contact arrangement (1NC + 1NO) before replacement.
• Requires a compatible 30 mm mounting panel hole.
• Disconnect power before installation.
• Verify whether additional contact blocks or accessories are needed for the application.
