A-B 802-TNPTP Limit Switch

Product Overview

The Allen-Bradley 802T-NPTP is a metal plug-in oiltight limit switch with a lever-type, spring-return actuator and neutral-position operation. It features NEMA Type 4 and 13 construction and a 4-circuit configuration for industrial machine-position sensing.

Key Technical Specifications

Rockwell Automation currently lists the 802T-NPTP as an active product.

Advantages & Features

• Rugged metal construction
• NEMA 4 and 13 oiltight enclosure
• Plug-in design for convenient installation and maintenance
• Spring-return lever mechanism
• Neutral-position operation
• 4-circuit configuration
• Suitable for harsh industrial environments
• Reliable mechanical position detection

Applications

• Industrial machinery
• Conveyor systems
• Material handling equipment
• Machine-position detection
• Automated production lines
• Packaging machinery
• Factory automation
• Equipment safety and control circuits

Important Notes

• The 802T-NPTP is a complete switch without a preselected operating lever; the appropriate lever must be selected for the application.
• Verify the required contact configuration and operating direction before installation.
• Do not exceed the specified mechanical travel.
• Ensure proper sealing of conduit connections to maintain the intended environmental protection.
• Installation and electrical connections should be performed by qualified personnel.
