A-B 802-MCW1A Limit Switch

Product Overview

The Allen-Bradley 802MC-W1A is a corrosion-resistant operating lever/actuator for Bulletin 802MC limit switches. It is part of the 802MC pre-wired, factory-sealed limit switch family and is designed for industrial position-sensing applications. Rockwell identifies 802MC-W1A as an 802MC Limit Switch Actuator, not a complete limit switch.

Key Technical Specifications

Advantages & Features

• Corrosion-resistant construction for demanding environments
• Designed specifically for 802MC limit switches
• Spring-return lever operation
• Easy to install and replace
• Rugged design for industrial applications
• Suitable for frequent mechanical actuation

Applications

• Industrial machinery
• Conveyor systems
• Material handling
• Machine position detection
• Factory automation
• Packaging equipment
• Harsh or corrosion-prone industrial environments

Important Notes

• 802MC-W1A is an actuator/operating lever, not a complete limit switch.
• Verify that the existing switch is from the 802MC series before ordering.
• Contact configuration, electrical ratings, and enclosure specifications depend on the complete 802MC switch assembly.
• Follow the manufacturer's installation instructions and verify actuator travel before operation.
