A-B 800F-X01S Push Button Operator

Product Overview

The Allen-Bradley 800F-X01S is a 22.5 mm self-monitoring normally closed (N.C.) contact block for the Bulletin 800F push-button operator family. It uses screw termination and is designed for industrial control panels and operator stations. Rockwell Automation lists it as an active product.

Key Technical Specifications

Specifications are based on Rockwell Automation's current product information.

Advantages & Features

• Self-monitoring N.C. contact for reliable control circuits
• Compact 22.5 mm design
• High 10 A thermal current rating
• Screw terminals for secure wiring
• Designed for demanding industrial applications
• High mechanical durability
• Compatible with the Allen-Bradley 800F push-button family

Applications

• Industrial control panels
• Machine control systems
• Factory automation
• Motor control circuits
• Operator control stations
• Industrial machinery
• Safety and control circuits

Important Notes

• 800F-X01S is a contact block, not the complete push-button operator.
• Verify the required N.C. contact configuration before ordering.
• Use compatible 800F series operators and mounting components.
• Follow the specified wire size and terminal tightening torque during installation.
• Disconnect power before installation or servicing.
