A-B 800T-XD2P Contact Block

A-B 800T-XD2P Contact Block

A-B 800T-XD2P Contact Block

  • Item NO.:

    800T-XD2P
  • Payment:

    T/T
  • Price:

    $2465
  • Product Origin:

    USA
  • Color:

    NEW
  • Product weight:

    0.01KG
  • Lead Time:

    In stock

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.Quality packing for each product

                                                                                                                                                                            •
                                                                                                                                                                                        1.
                                                                                                                                                                                          • Allen‑Bradley 800T‑XD2P Sealed Contact Block

                                                                                                                                                                                            Overview

                                                                                                                                                                                            800T‑XD2P is a heavy-duty fully sealed 1NC contact block for Rockwell Bulletin 800T / 800H series 30mm industrial pushbutton operators, used for control signal switching in machine safety and PLC input circuits. The sealed internal contact structure resists oil mist, dust and water splash, ideal for harsh workshop, food washdown and outdoor cabinet environments. It adopts side stacking modular design, can be combined with multiple contact blocks to expand circuit points for emergency stop, safety interlock and status feedback circuits.
                                                                                                                                                                                            800T-XD2P Contact Block


                                                                                                                                                                                            Core Model & Parameter Specifications

                                                                                                                                                                                            Contact Definition

                                                                                                                                                                                            • Contact configuration: 1 Normally Closed (1NC) sealed contact
                                                                                                                                                                                            • Utilization category: A600 / AC‑15, Q600 / DC‑13
                                                                                                                                                                                            • Max rated voltage: 600V AC/DC
                                                                                                                                                                                            • Thermal continuous current: 10A; breaking current: 5A
                                                                                                                                                                                              • AC: 5A @ 120V, 3A @ 240V
                                                                                                                                                                                              • DC: 3A @ 24V control signal circuit
                                                                                                                                                                                            • Terminal type: Screw clamp terminals
                                                                                                                                                                                              • Applicable wire: 14–18 AWG solid/stranded copper wire
                                                                                                                                                                                              • Tightening torque: 6–8 lb‑in (0.7–0.9 N·m)

                                                                                                                                                                                            Sealing & Environmental Performance

                                                                                                                                                                                            • Internal fully sealed contact chamber, NEMA Type 4 / 4X / 13 watertight & oiltight
                                                                                                                                                                                            • Front panel matching IP65 protection, terminal area IP20
                                                                                                                                                                                            • Operating temperature: -25℃ ~ +60℃; storage -40℃ ~ +85℃
                                                                                                                                                                                            • Mechanical service life: ≥10 million actuation cycles
                                                                                                                                                                                            • Shock resistance: 100G; vibration withstand: 10G

                                                                                                                                                                                            Mechanical Mounting

                                                                                                                                                                                            • Matching operator size: 30.5mm cutout 800T / 800H pushbuttons (e.g. 800H‑QR10A illuminated button)
                                                                                                                                                                                            • Installation method: Side stackable modular snap-on mounting, no tools required for assembly/disassembly
                                                                                                                                                                                            • Multiple blocks can be stacked on one single button operator to form multi-circuit control

                                                                                                                                                                                            Key Functions

                                                                                                                                                                                            1. Sealed contact anti-pollution switching

                                                                                                                                                                                              Totally enclosed contact cavity prevents dust, oil mist, cooling water from causing contact oxidation or short-circuit, stable signal output in chemical, food, mining harsh workshops.
                                                                                                                                                                                            2. Safety circuit NC signal transmission

                                                                                                                                                                                              NC contact is widely used for emergency stop, safety door interlock, rope pull switch feedback signals, paired with 440R‑N23126 safety relay to build dual redundant safety monitoring loops.
                                                                                                                                                                                            3. PLC digital input signal collection

                                                                                                                                                                                              Convey equipment stop, fault, safety trigger status to SLC 500 / MicroLogix 1200 PLC DI modules, upload alarm data to HMI touch panel.
                                                                                                                                                                                            4. Modular multi-circuit expansion

                                                                                                                                                                                              Stack multiple XD2P NC blocks or XD1P NO blocks on one pushbutton to realize independent control loops without extra panel space.
                                                                                                                                                                                            5. Quick maintenance replacement

                                                                                                                                                                                              Snap-on design allows fast disassembly without removing the entire pushbutton from cabinet door, shortens equipment downtime during contact aging replacement.

                                                                                                                                                                                            Compatible Matching Equipment

                                                                                                                                                                                            1. Pushbutton Operators

                                                                                                                                                                                              800T series heavy-duty buttons, 800H washdown buttons (800H‑QR10A amber illuminated pushbutton)
                                                                                                                                                                                            2. Safety Components

                                                                                                                                                                                              440R‑N23126 dual-channel safety relay, 440E‑A13501 rope pull switch contact block
                                                                                                                                                                                            3. PLC & Terminals
                                                                                                                                                                                            • SLC 500: 1747‑L532 CPU + 1746 digital input modules
                                                                                                                                                                                            • MicroLogix 1200: 1762‑L40BWA + 1762‑RPLRTB40 replacement terminal block
                                                                                                                                                                                            1. Distribution & Network

                                                                                                                                                                                              140M‑I8P‑C50S motor protection circuit breaker, 1783‑MMX14T2S Stratix managed Ethernet switch
                                                                                                                                                                                            2. HMI System

                                                                                                                                                                                              Allen‑Bradley PanelView, GE IC755CSW07CDA industrial touch screen

                                                                                                                                                                                            Typical Industrial Applications

                                                                                                                                                                                            • Packaging machine emergency stop & safety door interlock circuits
                                                                                                                                                                                            • Food & beverage washdown production line control panels
                                                                                                                                                                                            • Conveyor belt rope pull safety signal feedback
                                                                                                                                                                                            • Water treatment pump station local stop button signal collection
                                                                                                                                                                                            • Metal processing, mining machinery heavy-duty control stations

The structure and details of the product:
