A-B 800H-QR10A Push Button Operator

A-B 800H-QR10A Push Button Operator

A-B 800H-QR10A Push Button Operator

  • Item NO.:

    800H-QR10A
  • Payment:

    T/T
  • Price:

    $2465
  • Product Origin:

    USA
  • Color:

    NEW
  • Product weight:

    0.01KG
  • Lead Time:

    In stock

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.Quality packing for each product

                                                                                                                                                                            •
                                                                                                                                                                                        1. Allen‑Bradley 800H-QR10A Illuminated Momentary Push Button

                                                                                                                                                                                          Overview

                                                                                                                                                                                          800H-QR10A belongs to Rockwell Bulletin 800H series 30mm industrial illuminated momentary push button, plastic reinforced polyester construction, NEMA Type 4/4X washdown rated, widely installed on machine control panels for manual start/stop, jog, reset and equipment status trigger signals, matched with Rockwell PLC, safety relays and HMI systems.
                                                                                                                                                                                          800H Series Illuminated Pushbutton


                                                                                                                                                                                          Model Code Breakdown

                                                                                                                                                                                          • 800H: 30mm plastic industrial pushbutton series, NEMA 4X corrosion resistant
                                                                                                                                                                                          • QR: Full voltage illuminated round extended head, incandescent lamp base
                                                                                                                                                                                          • 10: Illumination voltage 120V AC/DC
                                                                                                                                                                                          • A: Amber transparent lens cap

                                                                                                                                                                                          Core Technical Specifications

                                                                                                                                                                                          Mechanical & Panel Mount

                                                                                                                                                                                          • Panel cutout diameter: 30.5 mm standard hole
                                                                                                                                                                                          • Operation type: Momentary spring return (releases automatically after pressing)
                                                                                                                                                                                          • Head style: Extended round illuminated head, no protective guard
                                                                                                                                                                                          • Mounting: Panel front mounting with lock nut & sealing gaskets
                                                                                                                                                                                          • NEMA enclosure rating: Type 1, 4, 4X, 12, 13 (waterproof, dustproof, washdown compatible)
                                                                                                                                                                                          • Mechanical service life: ≥250,000 actuation cycles
                                                                                                                                                                                          • Shock resistance: 100G without permanent damage; Vibration 10G max
                                                                                                                                                                                          • Operating temperature: -25℃ ~ +60℃; Storage -40℃ ~ +85℃

                                                                                                                                                                                          Illumination Circuit

                                                                                                                                                                                          • Lamp type: Incandescent full-voltage bulb
                                                                                                                                                                                          • Rated lamp voltage: 120V AC/DC
                                                                                                                                                                                          • Lens color: Amber (yellow-orange)
                                                                                                                                                                                          • Termination: Screw terminals for lamp wiring, wire range 14–18 AWG

                                                                                                                                                                                          Contact Block Standard Rating (1NO standard matching)

                                                                                                                                                                                          • Contact configuration: 1 Normally Open (1NO) standard contact block
                                                                                                                                                                                          • Utilization categories: AC-15 / A600; DC-13 / Q600
                                                                                                                                                                                          • Max operating voltage: 600V AC/DC
                                                                                                                                                                                          • AC load capacity: 3600VA make / 360VA break @120V
                                                                                                                                                                                          • DC load capacity: 5A @24V DC
                                                                                                                                                                                          • Electrical contact life: 1,000,000 cycles under full rated load
                                                                                                                                                                                          • Terminal torque: 6–8 in-lb (0.7–0.9 N·m) screw tightening

                                                                                                                                                                                          Protection & Certification

                                                                                                                                                                                          • IP front panel: IP65 sealed lens; terminal compartment IP20
                                                                                                                                                                                          • Certifications: UL, CE, CSA, CCC, EAC certified

                                                                                                                                                                                          Key Functions

                                                                                                                                                                                          1. Illuminated momentary manual operation

                                                                                                                                                                                            Amber lamp lights up when 120V power is applied to the lamp circuit; momentary NO contact closes while pressed, sends trigger signal to PLC digital input for start, jog, reset functions.
                                                                                                                                                                                          2. Washdown industrial sealing

                                                                                                                                                                                            4X rated housing resists water splash, dust, chemical mist, suitable for food, beverage, water treatment and outdoor factory cabinet panels.
                                                                                                                                                                                          3. Modular expandable design

                                                                                                                                                                                            Supports stacking additional contact blocks (add NC safety contacts) for dual-channel safety circuits paired with 440R-N23126 safety relay.
                                                                                                                                                                                          4. Visual equipment status indication

                                                                                                                                                                                            Constant amber illumination indicates equipment ready/auto mode; lamp off signals fault/stop state for on-site operator quick identification.
                                                                                                                                                                                          5. Universal panel compatibility

                                                                                                                                                                                            Standard 30mm cutout fits all standard industrial control cabinet doors, compatible with existing 800T/800H series button mounting hardware.

                                                                                                                                                                                          Compatible Supporting Automation Equipment

                                                                                                                                                                                          1. PLC Controllers
                                                                                                                                                                                          • SLC 500 (1747-L532) + 1746 digital input modules
                                                                                                                                                                                          • MicroLogix 1200 (1762-L40BWA) + 1762-RPLRTB40 terminal block
                                                                                                                                                                                          1. Safety & Power Components

                                                                                                                                                                                            440R-N23126 safety relay, 140M-I8P-C50S motor protection circuit breaker, 120V control power supply
                                                                                                                                                                                          2. Network & HMI

                                                                                                                                                                                            1783-MMX14T2S Stratix managed switch, PanelView / GE IC755CSW07CDA touch HMI
                                                                                                                                                                                          3. Safety Field Devices

                                                                                                                                                                                            440E-A13501 rope pull switch, safety door interlocks, light curtains

                                                                                                                                                                                          Typical Industrial Applications

                                                                                                                                                                                          • Packaging machinery start/jog control panels
                                                                                                                                                                                          • Municipal water & wastewater pump station local operation buttons
                                                                                                                                                                                          • Food & beverage washdown production line operator stations
                                                                                                                                                                                          • Conveyor, material handling equipment manual reset buttons
                                                                                                                                                                                          • General factory machine tool ready-status illuminated pushbuttons

The structure and details of the product:
