Allen‑Bradley 2090-CFBM7DF-CEAF60 Continuous-Flex Servo Motor Feedback Cable

1. Model Code Full Decoding

• 2090: Kinetix series servo dedicated cable family
• CFB: Motor feedback encoder cable (only position signal, no power/brake lines)
• M7: Match MP‑Series servo motors with 12‑pin M23 SpeedTec DIN motor connector
• DF: Drive end = flying loose wires (no pre-assembled D-Sub plug)
• CEAF: Continuous‑flex dynamic bending cable, TPE green jacket
• 60: Total cable length = 60 meters

2. Core Hardware Specifications

Connector Configuration

• Motor side: M23 12‑pin male right-angle SpeedTec DIN connector (IP65 when mated to MP motor)
• Drive side: Unterminated flying lead wires (no plug, on-site crimp to drive feedback terminal)
• Supported encoder: Sin/Cos high-resolution incremental encoder, resolver, multi-turn absolute encoder for MP rotary/linear servo motors

Cable Mechanical & Electrical

• Cable type: Continuous-flex dynamic drag-chain rated, suitable for reciprocating motion axes
• Outer jacket: Green TPE thermoplastic elastomer, oil-resistant, abrasion-resistant
• Shield structure: Double shielding (aluminum foil + copper braid), full 360° shield backshell grounding to suppress servo EMI interference
• Rated voltage: 600V signal cable
• Wire gauge: 22 AWG twisted differential pairs for encoder A/B/Z, power & temperature feedback
• Minimum bend radius: Static 6× cable OD; dynamic continuous flex 10× cable OD
• Operating temperature: -20℃ ~ +80℃
• Length: 60m long-distance wiring for large workshop distributed servo axes

Flex Performance

• Dynamic bending cycle life ≥10 million cycles for drag chain continuous reciprocation
• Distinction vs standard static cable: CEAA suffix = fixed static installation; CEAF = continuous flex drag chain use

3. Compatible Drive & Motor Equipment

Servo Drive

• 2094-BC02-M02-M (460V IAM servo drive, matched servo system)
• Full BCxx / AMxx / BMxx series Kinetix 6000 drives

Servo Motors

Supporting Automation Components

1. Motion control: ControlLogix PLC + Studio 5000 motion programming
2. Power distribution: 140M-I8P-C50S motor protection circuit breaker
3. Safety circuit: 440R-N23126 safety relay, 440E-A13501 rope pull switch
4. Network: 1783-MMX14T2S Stratix managed Ethernet switch
5. HMI: GE IC755CSW07CDA touch panel, Allen‑Bradley PanelView series

4. Main Functions

1. High-precision position feedback transmission

   Transmit differential encoder A/B/Z pulse, resolver sine/cosine signals from MP motor back to Kinetix 6000 drive, realize closed-loop position/velocity/torque control for high-speed positioning, electronic cam, winding tension control.
2. Long-distance 60m stable signal transmission

   Double shielding design eliminates long-distance EMI interference, avoids position jitter, encoder loss faults in large assembly lines, printing & textile winding equipment.
3. Drag chain continuous dynamic operation

   Continuous-flex construction resists repeated bending fatigue, ideal for reciprocating robot axes, gantry cutting machines, packaging reciprocating stations.
4. Multi-signal integration single cable

   Integrates encoder differential signals, motor temperature thermal feedback, encoder power supply in one cable, simplifies cabinet wiring layout.
5. Flying lead drive-end flexibility

   Loose wire terminal design allows custom wiring to drive feedback terminals, adapts to special cabinet wiring layout without fixed D-Sub plug length limitation.
