A-B 800FP-SM22PX10 Push Button Contact Block

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • • • • • • • • • • • • • •

                                            • Product Overview

                                              The Allen-Bradley 800FP-SM22PX10 is a 22 mm, two-position maintained selector switch from Rockwell Automation's Bulletin 800F series. It features a black plastic operator, a standard knob, and one normally open (NO) contact block for industrial control applications.



                                              US

                                              +1



                                              Technical Specifications

                                              Parameter	Specification
                                              Brand	Allen-Bradley
                                              Manufacturer	Rockwell Automation
                                              Model	800FP-SM22PX10
                                              Product Series	Bulletin 800F
                                              Product Type	Selector Switch
                                              Mounting Diameter	22.5 mm
                                              Number of Positions	2
                                              Operating Function	Maintained / Latching
                                              Operator Color	Black
                                              Operator Material	Plastic
                                              Contact Configuration	1 NO
                                              Contact Thermal Current Rating	10 A
                                              Maximum Operational Voltage	600 V (A600/Q600 rating)
                                              Electrical Connection	Screw terminals
                                              Wire Range	18–12 AWG (0.75–2.5 mm²)
                                              Tightening Torque	0.7–0.9 N·m
                                              Protection Rating	IP66, Type 4/4X/13 with compatible round plastic operator
                                              Lifecycle Status	Active

                                              Specifications: Rockwell Automation official product documentation.



                                              US

                                              +1



                                              Key Features

                                              • Two-position maintained selector operation.

                                              • One normally open contact for control-circuit switching.

                                              • Black plastic operator with standard knob.

                                              • Standard 22.5 mm panel mounting.

                                              • Screw-terminal wiring for industrial control panels.

                                              • Designed for use in automation and machine-control systems.

                                              Typical Applications

                                              • PLC control cabinets

                                              • Machine start/stop or mode selection circuits

                                              • Industrial operator panels

                                              • Equipment control and status selection

                                              • Factory automation systems

                                              Installation Notes

                                              • Verify the contact configuration and wiring diagram before installation.

                                              • Confirm the panel cutout is 22.5 mm.

                                              • Tighten terminals to the specified torque.

                                              • Ensure the assembled switch meets the required environmental protection rating.
