A-B 800FP-SM32PX20 Push Button Contact Block

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • • • • • • • • • • • • • • •

                                              • Product Overview

                                                The Allen-Bradley 800FP-SM32PX20 is a three-position maintained selector switch from Rockwell Automation's Bulletin 800F series. It features a black plastic operator with a standard knob and two normally open (NO) contact blocks for industrial control applications.



                                                US

                                                +1



                                                Technical Specifications

                                                Parameter	Specification
                                                Brand	Allen-Bradley
                                                Manufacturer	Rockwell Automation
                                                Model	800FP-SM32PX20
                                                Product Series	Bulletin 800F
                                                Product Type	Selector Switch
                                                Mounting Hole Diameter	22.5 mm
                                                Number of Positions	3
                                                Operating Function	Maintained / Latching
                                                Operator Color	Black
                                                Operator Material	Plastic
                                                Contact Configuration	2 NO
                                                Contact Thermal Current Rating	10 A
                                                Maximum Contact Rating	600 V (A600/Q600)
                                                Electrical Connection	Screw terminals
                                                Wire Range	18–12 AWG (0.75–2.5 mm²)
                                                Terminal Tightening Torque	0.7–0.9 N·m
                                                Protection Rating	IP66, Type 4/4X/13 with compatible operator
                                                Lifecycle Status	Active

                                                Source: Rockwell Automation official product specifications.



                                                US

                                                +1



                                                Key Features

                                                • Three-position maintained selector operation.

                                                • Two normally open contact blocks.

                                                • Black plastic operator with a standard knob.

                                                • Standard 22.5 mm panel-mount design.

                                                • Screw-terminal connections for industrial control wiring.

                                                • Designed for repeated operation in automation control panels.

                                                Typical Applications

                                                • PLC control cabinets

                                                • Manual/automatic mode selection

                                                • Industrial machine control

                                                • Equipment operating-mode selection

                                                • Factory automation operator panels

                                                Installation Notes

                                                • Verify the contact configuration and wiring diagram before installation.

                                                • Confirm the panel cutout is 22.5 mm.

                                                • Tighten terminals to the manufacturer's specified torque.

                                                • Disconnect power before wiring or servicing.

                                                • Check the switching logic for all three positions before commissioning.
