A-B 800FP-P4PN7R Push Button Operator

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • • • • • • • • • • • • •

                                          • Product Overview

                                            The Allen-Bradley 800FP-P4PN7R is a 22 mm red LED pilot light from Rockwell Automation's Bulletin 800F series. It is designed for visual status indication in industrial control panels and features a plastic operator body with an integrated 240 V AC LED.



                                            US

                                            +1



                                            Technical Specifications

                                            Parameter	Specification
                                            Brand	Allen-Bradley
                                            Manufacturer	Rockwell Automation
                                            Model	800FP-P4PN7R
                                            Product Series	Bulletin 800F
                                            Product Type	LED Pilot Light / Indicator
                                            Mounting Hole Diameter	22.5 mm
                                            Lens Color	Red
                                            Light Source	Integrated LED
                                            LED Voltage	240 V AC
                                            Operator Material	Plastic
                                            Lens Shape	Round, diffuse
                                            Connection Type	Screw terminals
                                            Protection Rating	IP66, Type 4/4X/13; compatible assemblies may offer IP69K
                                            Lifecycle Status	Active

                                            Specifications are based on Rockwell Automation's official product documentation.



                                            US

                                            +1



                                            Key Features

                                            • Integrated red LED for clear visual status indication.

                                            • 240 V AC LED illumination.

                                            • Standard 22.5 mm panel-mount design.

                                            • Plastic operator construction with a round red lens.

                                            • Screw-terminal electrical connections.

                                            • Designed for industrial control-panel environments.

                                            Typical Applications

                                            • PLC control cabinets

                                            • Machine status indication

                                            • Industrial automation panels

                                            • Equipment operating-status monitoring

                                            • Operator stations and control desks

                                            Installation Notes

                                            • Verify the LED supply voltage is 240 V AC before installation.

                                            • Confirm the panel cutout diameter is 22.5 mm.

                                            • Check terminal connections and wiring insulation before energizing.

                                            • Ensure the assembled operator meets the required environmental protection rating.
