- - Allen‑Bradley 440R-N23126 (MSR127T) Dual‑Channel Safety Relay

    440R-N23126 Safety Relay

    Overview

    440R-N23126 is a Guardmaster Minotaur series dual-channel safety monitoring relay, model MSR127T, designed for machine safety circuits. It monitors emergency stop buttons, safety interlock switches, light curtains and safety mats, achieving Category 4 / PL e safety level to cut dangerous machine motion reliably when safety signals trigger fault conditions. It adopts red industrial safety housing, standard DIN rail mounting, widely matched with SLC 500, Micro800, ControlLogix PLC systems.

    Core Specifications

    Power Supply

    Rated voltage: 24V AC/DC (50/60Hz)

    Operating range: 18–30V AC/DC

    Housing width: 22.5mm slim body

    Input Circuit (Dual Channel)

    Dual-channel NC safety input (S11, S12 / S21, S22)

    Supports dual-channel emergency stop, safety door interlock, light curtain

    Built-in cross-channel short-circuit fault detection

    Contact Configuration

    Safety outputs (instantaneous): 3 × NO safety contacts (13-14, 23-24, 33-34)

    AC15 rating: 250V / 5A

    DC13 rating: 24V / 3A

    Auxiliary feedback contact: 1 × NC monitoring contact (41-42)

    Used for PLC fault signal feedback, alarm indication

    Reset Mode

    Dual-mode selectable: Automatic reset / Manual reset

    Manual reset: Requires external reset button to reset after safety trip

    Auto reset: Automatically closes outputs once safety hazard is removed

    Mechanical & Environmental

    Mounting: 35mm standard DIN rail

    Terminal type: Fixed screw terminals (non-detachable)

    Protection class: Housing IP40, terminals IP20

    Operating temperature: -5℃ ~ +55℃

    Impulse withstand voltage: 2500V

    Weight: ~214g

    Safety Certification & Standards

    Safety performance: Cat.4, PL e, SIL3

    Compliant standards: ISO 13849-1, EN 954-1, IEC 60204-1, cULus, CE, BG approved

    Key Functions

    Dual-channel fault self-monitoring

    Detects short/open circuit between two safety input lines; if single-channel fault occurs, the safety relay locks trip status to prevent dangerous hidden failures.

    Category 0 safe stop

    3 groups of independent safety NO contacts cut main contactor coil power simultaneously to realize hard-wired safety stop of machine motors.

    Dual reset logic

    Switch between auto/manual reset via internal jumper, adapting to different machine safety regulations (manual reset required for most fixed machinery).

    Fault signal feedback

    1NC auxiliary contact outputs trip status to PLC digital input module for HMI alarm display and fault logging.

    Series expansion capability

    Multiple MSR127T safety relays can be cascaded to monitor multiple safety zones of large production lines.

    Real-time status LED indication

    PWR: Power supply status

    CH1 / CH2: Dual safety channel signal status

    Quick on-site troubleshooting without measuring instruments.

    Compatible Equipment

    Safety field devices

    Emergency stop pushbuttons, safety door interlock switches, safety light curtains, safety mats (dual NC contact type)

    Rockwell PLC systems

    SLC 500 (1747-L532 CPU + 1746 series DI modules)

    Micro800, ControlLogix 1756 series

    Auxiliary components

    AC contactors, PanelView HMI touch panels, circuit breakers, 24V power supply
