A-B 1783-MMX14T2S Stratix Managed Ethernet Switch

A-B 1783-MMX14T2S Stratix Managed Ethernet Switch

A-B 1783-MMX14T2S Stratix Managed Ethernet Switch

  • Item NO.:

    1783-MMX14T2S
  • Payment:

    T/T
  • Price:

    $2465
  • Product Origin:

    USA
  • Color:

    NEW
  • Product weight:

    0.01KG
  • Lead Time:

    In stock

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.Quality packing for each product

                                                                                                                                                                            •
                                                                                                                                                                              •

                                                                                                                                                                                Allen‑Bradley 1783‑MMX14T2S Stratix 5700 Managed Industrial Ethernet Switch



                                                                                                                                                                                Overview


                                                                                                                                                                                1783‑MMX14T2S belongs to Rockwell Stratix 5700 compact managed industrial switch series, designed for factory automation, power water treatment and machine control networks. It provides 14 copper RJ45 ports + 2 SFP fiber slots, full Layer 2 managed switching functions, supports industrial network redundancy, security and traffic control, perfectly matched with SLC 500, ControlLogix, Micro800 PLC and QuickPanel HMI systems.

                                                                                                                                                                                Core Hardware Specifications



                                                                                                                                                                                Port Configuration


                                                                                                                                                                                • 14 × 10/100/1000 Mbps auto‑sensing RJ45 copper ports (CAT5e/CAT6 shielded cable)
                                                                                                                                                                                • 2 × SFP gigabit fiber expansion slots (support multi‑mode / single‑mode SFP transceivers, sold separately)
                                                                                                                                                                                • All ports support auto MDI/MDI‑X, IEEE 802.3af PoE optional (base model non‑PoE)
                                                                                                                                                                                • Port status LED: Link/Activity, speed, fault alarm per port

                                                                                                                                                                                Mechanical & Power


                                                                                                                                                                                • Input power: 24V DC (18–30V DC) industrial control power
                                                                                                                                                                                • Mounting: Standard 35mm DIN rail; optional panel mounting brackets
                                                                                                                                                                                • Enclosure: IP30 metal housing, dustproof for indoor cabinet
                                                                                                                                                                                • Operating temperature: -40°C ~ +60°C wide temperature range
                                                                                                                                                                                • Relative humidity: 5%–95% non‑condensing
                                                                                                                                                                                • Dimensions: Compact slim industrial rack form factor
                                                                                                                                                                                • Certification: cULus, CE, Class I Div.2 hazardous location compliant

                                                                                                                                                                                Layer 2 Managed Switch Core Functions


                                                                                                                                                                                1. Industrial network redundancy protocols
                                                                                                                                                                                • Device Level Ring (DLR): Rockwell proprietary ring network, fast fault recovery <5ms
                                                                                                                                                                                • Rapid Spanning Tree RSTP/MSTP: Prevent network loop for star/daisy chain topology
                                                                                                                                                                                • Parallel Redundancy Protocol (PRP): Zero switchover loss for high‑reliability power substation networks
                                                                                                                                                                                1. Traffic scheduling & QoS (IEEE 802.1p)

                                                                                                                                                                                  4 priority queues per port, real‑time industrial control traffic (EtherNet/IP, Modbus TCP) prioritized to avoid PLC communication delay.
                                                                                                                                                                                2. VLAN & network segmentation

                                                                                                                                                                                  802.1Q tagged VLAN, isolate control network, HMI monitoring network and IT office network to enhance safety and stability.
                                                                                                                                                                                3. Advanced security features
                                                                                                                                                                                • Port security, MAC address binding to block unauthorized device access
                                                                                                                                                                                • 802.1X port authentication
                                                                                                                                                                                • Broadcast storm suppression to avoid network flooding fault
                                                                                                                                                                                • Access control list ACL for data filtering
                                                                                                                                                                                1. Network monitoring & diagnosis
                                                                                                                                                                                • SNTP time synchronization for unified device timestamps
                                                                                                                                                                                • Port mirroring for offline fault capture analysis
                                                                                                                                                                                • SNMP v1/v2c/v3, web GUI, CLI command line configuration
                                                                                                                                                                                • Fault alarm via relay contact output to PLC DI module
                                                                                                                                                                                1. Industrial automation protocol support

                                                                                                                                                                                  Native optimized for EtherNet/IP (Rockwell PLC communication), compatible with Modbus TCP, IEC 61850, OPC UA, SRTP, EGD.

                                                                                                                                                                                Typical Matching Automation Equipment


                                                                                                                                                                                1. Rockwell PLC systems
                                                                                                                                                                                • SLC 500 (1747‑L532) + 1747‑KE Ethernet module
                                                                                                                                                                                • ControlLogix 1756 series, Micro800 series
                                                                                                                                                                                1. HMI & IED devices
                                                                                                                                                                                • Allen‑Bradley PanelView Plus touch screens
                                                                                                                                                                                • GE QuickPanel+ IC755CSW07CDA HMI
                                                                                                                                                                                • Substation protection relays, flow meters, vibration monitors
                                                                                                                                                                                1. Other network devices

                                                                                                                                                                                  IC695ETM001 / IC695ECM850 Ethernet modules for GE RX3i PLC, industrial fiber SFP transceivers, safety relays 440R‑N23126

                                                                                                                                                                                Main Industrial Applications


                                                                                                                                                                                • Packaging machinery, robot assembly line EtherNet/IP control network
                                                                                                                                                                                • Thermal power plant auxiliary PLC redundant communication cabinet
                                                                                                                                                                                • Municipal water & sewage treatment distributed I/O monitoring network
                                                                                                                                                                                • Petrochemical plant Class I Div.2 hazardous area control network
                                                                                                                                                                                • Factory multi‑PLC interconnection with separate HMI monitoring subnet

                                                                                                                                                                                Key Notes


                                                                                                                                                                                1. This model does not include SFP fiber transceivers; transceivers must be purchased separately for long‑distance fiber wiring.
                                                                                                                                                                                2. DLR ring topology is recommended for production lines to minimize downtime during cable break faults.
                                                                                                                                                                                3. Separate switch signal cables from high‑voltage power cables in cable trenches to reduce electromagnetic interference.
                                                                                                                                                                                4. Configuration can be completed via built‑in web page or Rockwell Studio 5000 / RSLogix 500 software.
                                                                                                                                                                                5. Class I Div.2 certification allows installation in mild flammable gas industrial environments with compliant cabinet layout.
