A-B 2711R-T10T PanelView 800 HMI Terminal

Product Overview
The Allen-Bradley 2711R-T10T PanelView 800 is a 10-inch touchscreen HMI terminal designed for operator monitoring, machine control, and industrial visualization. It features a color TFT display, Ethernet and serial communication interfaces, USB and microSD support, and a 24 VDC power supply.

Technical Specifications

• Model: 2711R-T10T
• Series: PanelView 800
• Display: 10-inch color TFT LCD
• Resolution: 800 × 600 SVGA
• Colors: 65K
• Touchscreen: Analog resistive touch
• Backlight: LED, minimum 40,000 hours
• Ethernet: 1 × 10/100 Mbps
• Serial: RS-232; RS-422/RS-485
• USB: USB Host + USB Device
• Memory: 256 MB Flash / 256 MB DDR SDRAM
• Storage: microSD support, up to 32 GB
• Power Supply: 24 VDC nominal, 18–32 VDC
• Maximum Power: 14 W
• Dimensions: 225 × 287 × 55 mm
• Weight: Approx. 1.64 kg
• Enclosure Rating: NEMA 4X indoor, 12, 13; IP65
• RTC: Integrated real-time clock with replaceable battery
• Software: Connected Components Workbench (CCW)

Advantages & Features

• Large 10-inch touchscreen for clear machine visualization
• Ethernet and multiple serial communication interfaces
• Supports landscape and portrait application modes
• LED backlight with long service life
• USB and microSD for project/data transfer
• Integrated real-time clock
• Compact panel-mount design
• Optimized for Micro800 and MicroLogix controllers

Applications

• Machine automation
• Packaging equipment
• Material handling
• Production lines
• HVAC and air-handling systems
• Process monitoring
• Factory operator interfaces
