A-B MPS-B330P-M-X156 Servo Motor

Product Overview
The Allen-Bradley MPS-B330P-M-X156 is an MP-Series MPS stainless-steel low-inertia AC servo motor designed for demanding washdown and hygienic environments. It features a 400/460 VAC class, 5000 RPM operation, and absolute multi-turn high-resolution encoder feedback. Rockwell Automation currently lists the exact model as an active product.

Technical Specifications

• Model: MPS-B330P-M-X156
• Series: MP-Series MPS
• Type: Stainless-Steel AC Servo Motor
• Rated Voltage: 400/460 VAC class
• Phase: 3-Phase
• Frame Size: 100 mm
• Magnet Stack Length: 76.2 mm (3.0 in.)
• Rated / Maximum Speed: 5000 RPM
• Rated Output: 1.3 kW
• Continuous Stall Torque: 3.6 N·m
• Peak Stall Torque: 11.1 N·m
• Rotor Inertia: 0.00012 kg·m²
• Feedback: 1024 sin/cos absolute multi-turn encoder, Hiperface
• Shaft: Keyed shaft
• Brake: Installed
• Protection: IP66/IP67
• Mounting: IEC metric flange, tapped mounting holes
• Connector: Circular SpeedTec DIN, right-angle, 180° rotatable
• Weight: Approx. 7.4 kg (16.2 lb)

Advantages & Features

• Low-inertia design for fast acceleration and precise positioning
• Stainless-steel construction for demanding washdown environments
• High-resolution absolute multi-turn feedback
• Integrated holding brake
• IP66/IP67 protection
• Suitable for high-pressure and caustic washdown applications
• Compact 100 mm frame with 5000 RPM high-speed operation

Applications

• Food and beverage processing
• Meat and poultry equipment
• Dairy and brewing machinery
• Pharmaceutical manufacturing
• Packaging and filling machines
• Hygienic industrial automation
• Washdown motion-control systems
