A-B 22F-D2P5N113 PowerFlex 4M AC Drive

Product Description

Allen-Bradley 22F-D2P5N113 is a PowerFlex 4M Adjustable Frequency AC Drive (VFD) manufactured by Rockwell Automation. It is designed for controlling the speed, torque, and operation of three-phase AC motors in compact industrial automation applications.

This model provides a cost-effective motor control solution with built-in keypad, EMC filtering, RS485 communication, and compact IP20 panel-mount design.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 22F-D2P5N113
• Product Type: Variable Frequency Drive (VFD) / AC Drive
• Series: PowerFlex 4M
• Input Voltage: 480 VAC
• Input Phase: 3 Phase
• Rated Output Current: 2.5 A
• Power Rating: 0.75 kW (1 HP)
• Frame Size: Frame A
• Enclosure Rating: IP20 (Open Type)
• Display: LED Display
• Keypad: Fixed Digital Keypad with Potentiometer
• EMC Filter: Built-in CE Compliant EMC Filter
• Brake Function: No Brake IGBT
• Communication: Integral RS485 / DSI Port
• Frequency: 50/60 Hz

Functions

• Controls AC motor speed by adjusting output frequency
• Provides motor start/stop control
• Regulates motor torque and acceleration/deceleration
• Supports parameter configuration through keypad
• Provides RS485 communication for industrial networks
• Protects motors against overload and operating faults

Advantages & Features

• Compact design for limited cabinet space
• Easy installation and commissioning
• Built-in EMC filter reduces electrical interference
• Integrated keypad simplifies parameter adjustment
• Supports Modbus RTU communication through RS485
• Reliable Allen-Bradley PowerFlex drive technology
• Suitable for small motor speed control applications

Applications

• Conveyor systems
• Pumps and fans
• Packaging machinery
• Small production equipment
• Material handling systems
• Factory automation equipment
• Machine speed control applications

Notes

• 22F-D2P5N113 is an AC drive/VFD, not a PLC module
• Requires compatible 480VAC three-phase power input
• Confirm motor voltage and current before installation
• Verify parameter settings before running the motor
• This model does not include a built-in brake resistor transistor
