A-B 193-ESM-VIG-60A-T Electronic Overload Relay Module

Product Description

Allen-Bradley 193-ESM-VIG-60A-T is an E300/E200 Electronic Overload Relay Sensing Module manufactured by Rockwell Automation. It is used with the E300 Electronic Overload Relay system to provide motor protection functions, including current, voltage, ground fault, and power monitoring.

The module is designed for DIN rail or panel mounting and supports motor current ranges from 6 to 60 A, providing intelligent protection and diagnostic capabilities for industrial motor applications.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 193-ESM-VIG-60A-T
• Product Type: Electronic Overload Relay Sensing Module
• Series: E300 / E200 Electronic Overload Relay
• Module Type: V/I/GF Sensing Module
• Sensing Range: 6…60 A
• Functions:
  • Current sensing
  • Voltage sensing
  • Ground fault sensing
  • Power monitoring
• Maximum Motor Voltage: 20…600 VAC
• Mounting: DIN Rail / Panel Mount
• Protection Type: Electronic motor overload protection
• Trip Class: Adjustable (Class 5…30 depending on configuration)
• Communication Compatibility: Supports E300 communication/control modules

Functions

• Monitors motor operating current and voltage
• Protects motors from overload conditions
• Detects ground fault conditions
• Provides motor diagnostics and status information
• Measures electrical parameters for intelligent motor management
• Interfaces with E300 communication and control modules

Advantages & Features

• Advanced electronic motor protection technology
• Wide current adjustment range (6–60 A)
• Provides voltage, current, ground fault, and power monitoring
• Supports predictive maintenance through diagnostics
• Modular design allows flexible E300 system configuration
• DIN rail or panel mounting for easy installation
• Suitable for industrial motor control applications

Applications

• Motor control centers (MCC)
• Industrial automation equipment
• Pump and fan systems
• Conveyor systems
• Machine tools
• Factory production equipment
• Process control systems

Notes

• 193-ESM-VIG-60A-T is a sensing module, not a complete overload relay by itself
• Requires compatible E300 communication module and control module for a complete E300 overload relay system
• Verify motor full-load current before selection
• Confirm voltage and wiring configuration before installation
• Ensure compatibility with existing 193/592 E300 series components
