A-B 193-ESM-VIG-30A-T Electronic Overload Relay Module

Product Description

Allen-Bradley 193-ESM-VIG-30A-T is an E300/E200 Electronic Overload Relay Sensing Module manufactured by Rockwell Automation. It is part of the E300 intelligent motor protection system and provides voltage, current, and ground fault sensing for industrial motor protection applications.

This module is designed for DIN rail or panel mounting and supports motor full-load current ranges from 0.5 A to 30 A, allowing integration with E300 communication and control modules.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 193-ESM-VIG-30A-T
• Product Type: Electronic Overload Relay Sensing Module
• Series: E300 / E200 Electronic Overload Relay
• Module Type: V/I/GF Sensing Module
• Current Range: 0.5–30 A
• Maximum Motor Voltage: 20–600 VAC
• Functions:
  • Current sensing
  • Voltage sensing
  • Ground fault sensing
• Mounting: DIN Rail / Panel Mount
• Protection Rating: IP20
• Power Terminals: Line and load side conductor terminals

Functions

• Monitors motor current and voltage conditions
• Provides electronic overload protection
• Detects ground fault conditions
• Collects motor operating data for diagnostics
• Communicates motor status through E300 control modules
• Helps prevent motor damage caused by overload, phase loss, and abnormal operating conditions

Advantages & Features

• Intelligent electronic motor protection solution
• Wide current adjustment range (0.5–30A)
• Supports single-phase and three-phase motor applications
• Provides enhanced diagnostic information
• Modular design for flexible system configuration
• Compact DIN rail installation
• Compatible with Allen-Bradley E300 overload relay systems

Applications

• Motor Control Centers (MCC)
• Pumps and fan systems
• Conveyor equipment
• Industrial machinery
• Factory automation systems
• Process control equipment
• Production line motor protection

Notes

• 193-ESM-VIG-30A-T is a sensing module, not a complete overload relay by itself
• Requires compatible E300 communication module and control module to form a complete overload relay system
• Verify motor full-load current before selection
• Confirm voltage rating and wiring configuration before installation
• Check compatibility with existing E300 components before replacement
