Allen-Bradley 5069-OBV8S Compact 5000 Safety Output Module

Product Description

Allen-Bradley 5069-OBV8S is a Compact 5000 Safety Digital Output Module designed for GuardLogix 5380 safety controller systems. It provides reliable 24V DC safety output control for machine safety applications, supporting safety devices such as safety contactors, drives, and actuators.

Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 5069-OBV8S
• Series: Compact 5000 Safety I/O
• Product Type: Safety Digital Output Module
• Output Channels: 8 Channels
• Output Type: 24V DC Safety Configurable Output
• Output Voltage: 10…32V DC
• Output Current: 1 A per channel (maximum)
• Power Supply: 18…32V DC
• Isolation Voltage: 250V continuous basic isolation
• Mounting: DIN Rail Mount
• Communication: Compact 5000 Backplane
• Compatible Controllers: Compact GuardLogix 5380 Series
• Dimensions: Approx. 105 × 138 mm
• Operating Temperature: 0…60°C

Advantages & Features

• Provides reliable safety output control for industrial machinery
• Supports configurable safety output functions
• High-speed Compact 5000 backplane communication
• Compact 22 mm width design saves cabinet space
• Supports safety diagnostics and fault detection
• Suitable for Category 4 / high-performance safety applications when properly configured
• Easy integration with GuardLogix safety controllers

Applications

• Machine safety control systems
• Emergency stop circuits
• Safety contactor control
• Servo drive STO (Safe Torque Off) control
• Robotic safety systems
• Packaging machinery
• Automated production lines
• Industrial equipment protection

Notes

• Verify compatibility with the controller and Studio 5000 version before installation
• Confirm safety configuration parameters before operation
• Use correct 24V DC power supply and wiring method
• Safety functions must be tested after installation
• Ensure output load current does not exceed rated limits
• Follow Rockwell Automation safety installation guidelines
