A-B 194E-E63-1753-6N Disconnect Switch

Allen-Bradley 194E-E63-1753-6N Disconnect Switch

Product Description

The Allen-Bradley 194E-E63-1753-6N is a 63A IEC load disconnect switch designed for safe isolation and switching of industrial electrical circuits. It features a 3-pole design, OFF-ON 90° rotary operation, and a red/yellow handle, making it suitable for use as a main switch or maintenance/service disconnect in industrial control panels.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 194E-E63-1753-6N
• Product Type: Disconnect Switch / Load Switch
• Series: Bulletin 194E
• Rated Current: 63 A
• Number of Poles: 3 Poles
• Switch Position: OFF-ON (90° rotary)
• Rated Operational Voltage: Up to 690 VAC
• Rated Isolation Voltage: 690 VAC
• Rated Frequency: 50/60 Hz
• Rated Power:
  • AC-3: 18.5 kW @ 400/690 V
  • AC-23A: 30 kW @ 400 V
• Mounting: Front / door mounting
• Handle Type: Red/yellow rotary handle
• Terminal Connection: Screw connection
• Wire Range: 2.5…25 mm² (12…4 AWG)
• Protection Rating: IP20
• Mechanical Life: Approx. 200,000 operations
• Country of Origin: Poland

Advantages & Features

• Provides reliable equipment isolation for maintenance safety
• 3-pole load switching capability
• High visibility red/yellow handle design
• Suitable for main switch and service disconnect applications
• Compact design for industrial control cabinets
• Supports front/door mounting installation
• Durable mechanical operation for long service life

Applications

• Industrial control panels
• Motor control cabinets
• Machine power isolation
• Factory automation equipment
• Electrical distribution systems
• Maintenance safety disconnect applications

Notes / Precautions

• Confirm voltage and current ratings before installation.
• Ensure correct mounting method and handle configuration.
• Use appropriate upstream circuit protection.
• Installation should comply with local electrical safety standards.
