A-B 193-ESM-IG-100A-C97 Electronic Overload Relay

Allen-Bradley 193-ESM-IG-100A-C97 Electronic Overload Relay Module

Product Description

The Allen-Bradley 193-ESM-IG-100A-C97 is an E300/E200 Electronic Overload Relay Current & Ground Fault Sensing Module designed for advanced motor protection applications. It provides accurate motor current monitoring, overload protection, and ground fault detection. This sensing module mounts directly to Allen-Bradley 100-C60 through 100-C97 contactors and is used as part of an E300 electronic overload relay system.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 193-ESM-IG-100A-C97
• Product Type: Electronic Overload Relay Sensing Module
• Series: E300 / E200 Overload Relay
• Sensing Type: Current + Ground Fault Sensing
• Current Range: 10…100 A
• Maximum Motor Full Load Current: 100 A
• Mounting: Contactor mounted
• Compatible Contactors: 100-C60…100-C97 series contactors
• Protection Functions:
  • Motor overload protection
  • Phase loss detection
  • Current imbalance monitoring
  • Ground fault detection
• Protection Rating: IP20
• Country of Origin: Mexico

Advantages & Features

• Provides intelligent electronic motor protection
• Combines current sensing and ground fault monitoring
• Wide adjustable current range (10–100 A)
• Direct mounting design simplifies installation
• Improves motor reliability and reduces downtime
• Supports advanced diagnostics when integrated with E300 overload systems
• Compatible with Allen-Bradley motor control solutions

Applications

• Industrial motor protection systems
• Motor control centers (MCC)
• Pumps and fans
• Conveyors
• Compressors
• Machine automation equipment
• Factory production lines
• Industrial control panels

Notes / Precautions

• This item is a sensing module only, not a complete overload relay.
• Requires compatible E300/E200 overload relay components and contactor.
• Verify contactor size compatibility before installation.
• Confirm motor current settings according to the motor nameplate.
• Ensure proper grounding and wiring for ground fault detection.
