A-B 1783-CMS10P Ethernet Switch

Allen-Bradley 1783-CMS10P Stratix 5200 Ethernet Switch

Product Description

The Allen-Bradley 1783-CMS10P is a Stratix 5200 managed industrial Ethernet switch designed for high-speed industrial network communication. It provides Gigabit Ethernet connectivity for PLCs, HMIs, remote I/O, drives, and other automation devices. The switch supports Layer 2 managed switching functions and is designed for DIN rail mounting in industrial control cabinets.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1783-CMS10P
• Product Type: Managed Industrial Ethernet Switch
• Series: Stratix 5200
• Number of Ports: 10 ports
• Ethernet Ports:
  • 8 × Copper Gigabit Ethernet ports (100/1000 Mbps)
  • 2 × Combo ports (RJ45/SFP, 100/1000 Mbps)
• Network Type: Ethernet / EtherNet/IP
• Switch Type: Managed Layer 2 Switch
• Firmware: Full Firmware
• Mounting: DIN Rail mounting
• Protection Rating: IP30
• Operating Temperature: -40…60 °C
• Power Supply: Industrial DC power input
• Communication Functions:
  • VLAN support
  • Network diagnostics
  • Industrial Ethernet management functions
• Lifecycle Status: Active

Advantages & Features

• High-speed Gigabit Ethernet communication
• Supports industrial automation network architectures
• Managed switch functions improve network monitoring and troubleshooting
• Compatible with Rockwell Automation EtherNet/IP systems
• Supports copper and fiber uplink connectivity through combo ports
• Rugged industrial design for harsh environments
• DIN rail mounting saves control cabinet space

Applications

• ControlLogix / CompactLogix PLC networks
• Factory automation systems
• Industrial Ethernet infrastructure
• HMI and SCADA communication
• Remote I/O networks
• Motion control systems
• Machine automation equipment

Notes / Precautions

• Verify network topology and configuration requirements before installation.
• Confirm compatible SFP modules when using fiber connections.
• Ensure correct DC power supply and grounding.
• Configure IP address and managed switch parameters before operation.
• Check firmware compatibility with existing automation systems.
