A-B 100-C60DJ10 Contactor

Allen-Bradley 100-C60DJ10 Contactor

Product Description

The Allen-Bradley 100-C60DJ10 is a Bulletin 100-C IEC Contactor designed for reliable switching of three-phase motors and industrial electrical loads. It features a 60 A AC-3 rating, a 24 VDC coil with integrated diode, and 3 normally open (3NO) main contacts with 1 NO auxiliary contact. Its compact design and high electrical durability make it suitable for motor control centers, machinery, and industrial automation systems.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 100-C60DJ10
• Product Type: IEC Contactor
• Series: Bulletin 100-C
• Rated Operational Current (AC-3): 60 A
• Number of Main Poles: 3 NO
• Auxiliary Contacts: 1 NO, 0 NC
• Coil Voltage: 24 VDC with integrated diode
• Rated Operational Voltage: Up to 690 VAC (IEC), 600 VAC (UL)
• Motor Rating: Up to 32 kW @ 400/415 VAC
• Terminal Type: Screw terminals
• Coil Termination: Line side
• Protection Rating: IP20
• Mounting: Panel / DIN rail (with appropriate accessories)
• Lifecycle Status: Active

Advantages & Features

• Compact IEC contactor design
• 60 A AC-3 rating for motor control applications
• 24 VDC coil with integrated surge suppression diode
• 3 NO main contacts plus 1 NO auxiliary contact
• Screw terminals for secure wiring
• High mechanical and electrical durability
• Compatible with Allen-Bradley Bulletin 100-C accessories
• Suitable for industrial motor starters and automation systems

Applications

• Motor control centers (MCC)
• Industrial automation equipment
• Pumps and fans
• Conveyors
• Compressors
• Packaging machinery
• Material handling systems
• General industrial motor control

Notes / Precautions

• Verify the 24 VDC coil voltage before energizing.
• Ensure the load current does not exceed the 60 A AC-3 rating.
• Use appropriate overload protection for motor applications.
• Confirm compatibility with accessories and mounting hardware before installation.
