YOKOGAWA NFCP502-W05 Controller Module

YOKOGAWA NFCP502-W05 Controller Module (FCN / STARDOM CPU Module)





The Yokogawa NFCP502-W05 is a high-performance CPU module used in the Yokogawa STARDOM FCN (Field Control Node) system, designed for distributed control, logic execution, and industrial communication in automation and process control applications.

Basic Information

• Part Number: NFCP502-W05
• Brand: Yokogawa
• Series: STARDOM FCN / FCN-500 Series
• Type: Controller / CPU Module
• Function: Executes control logic, manages I/O, and handles network communication

Technical Specifications

• Processor: Intel Atom E3815, 1.46 GHz
• Main Memory: 256 MB ECC RAM
• SRAM: 2 MB ECC (battery-backed)
• Flash Memory: 1 GB onboard
• External Storage: SDHC card slot (4–32 GB)
• Ethernet Ports: 4 × RJ45 (10/100/1000 Mbps)
• Serial Port: 1 × RS-232-C
• Power Supply: 5 V DC ±5%
• Current Consumption: up to 1.7 A
• Bus System: SB bus (duplex)
• Operating System: Embedded industrial control platform (Yokogawa FCN runtime)

Key Features

• High-speed industrial CPU for real-time control applications
• Supports distributed control architecture (DCS/SCADA integration)
• 4 independent Ethernet ports for network redundancy and segmentation
• Battery-backed SRAM for secure data retention
• SD card expansion for program/data storage
• Built-in watchdog and system health monitoring (RAS functions)
• Designed for 24/7 continuous industrial operation

Application Areas

• Oil & gas automation systems
• Petrochemical plants
• Power generation systems
• Water treatment plants
• Factory automation / process control
• SCADA and distributed control networks
• Offshore and remote unmanned stations

System Role (Important)

The NFCP502-W05 acts as the core controller of a Field Control Node (FCN):

• Executes control logic (PID, sequencing, interlocks)
• Collects and processes I/O data
• Communicates with upper-level DCS systems (CENTUM VP)
• Handles local autonomous control when disconnected from host

Advantages

• High reliability industrial CPU design
• Strong network capability (4 Ethernet ports)
• Suitable for distributed / remote control systems
• Stable long-term operation in harsh environments
• Flexible storage and communication expansion
• Widely used in Yokogawa STARDOM architecture worldwide

Precautions

• Must be used in compatible Yokogawa FCN/STARDOM system
• Requires correct 5V regulated power supply
• Ensure proper SD card compatibility (industrial grade recommended)
• Battery-backed SRAM requires periodic battery maintenance
• Firmware version must match system configuration
