YOKOGAWA AIP830-001/EIM Operator Interface Panel

Product Description

YOKOGAWA AIP830-001/EIM is an Operation Keyboard / Operator Interface Panel designed for Yokogawa CENTUM VP Distributed Control System (DCS) single-loop operation. It provides operators with dedicated keys for monitoring and controlling single-loop control functions in industrial process automation systems.

The AIP830 is mainly used as an operator operation device, not as a PLC input/output module. It is typically installed with Yokogawa operator stations for process monitoring and control operations.

Specifications

• Brand: YOKOGAWA
• Model: AIP830-001/EIM
• Product Type: Operator Interface Panel / Operation Keyboard
• Series: AIP830
• Application: Single-loop Operation
• Function:
  • Process monitoring
  • Loop operation control
  • Operator command input
  • Control parameter adjustment

Model Configuration

• AIP830: Operation Keyboard for Single-loop Operation
• -0: Without mode selection switch
• 0: Operation confirmation key Type A
• /EIM: English Instruction Manual option

Technical Specifications

• Interface: USB interface
• Power Supply: 5V DC (USB bus powered)
• Maximum Current: Approx. 1A
• Weight: Approx. 2 kg
• Operating Temperature: 5–40°C
• Storage Temperature: -20–60°C
• Humidity: 20–80% RH (non-condensing)
• Mounting: Desktop / operator station installation
• Color: Black housing

Advantages & Features

• Dedicated operation device for Yokogawa DCS systems
• Provides convenient single-loop control operation
• Improves operator efficiency and control accuracy
• Ergonomic industrial keyboard design
• Reliable interface for continuous process operation
• Suitable for control room environments
• Supports Yokogawa CENTUM VP operation platforms

Applications

• Yokogawa CENTUM VP DCS systems
• Process control rooms
• Oil & gas plants
• Chemical processing facilities
• Power generation plants
• Refinery automation systems
• Industrial production monitoring systems

Notes

• AIP830-001/EIM is an operator keyboard/interface device, not an I/O module
• Requires compatible Yokogawa operator station or DCS configuration
• Confirm CENTUM system compatibility before replacement
• Check USB connection and operator station settings
• Follow Yokogawa system installation procedures
