- Woodward XR1

  Rotor Earth Fault Protection Relay (Not Governor Controller)

  Manufacturer: Woodward (原 SEG Electronics)

  Part No: XR1

  Type: Synchronous machine rotor earth fault protection relay (two‑stage: alarm + trip)

  Overview

  The Woodward XR1 is a DIN‑rail mounted protection relay for detecting rotor winding earth faults in synchronous generators/motors. It provides two‑stage protection (alarm for high‑resistance faults, trip for low‑resistance faults) to prevent rotor insulation damage and machine failure.

  Specifications

  Function: Rotor earth fault detection (high/low impedance)

  Protection Stages: 2 (alarm R<, trip R<<)

  Resistance Settings:

  Alarm (R<): 20–140 kΩ (continuous)wss.woodward.com

  Trip (R<<): 0–30 kΩ (continuous)wss.woodward.com

  Time Delays:

  Alarm (tR<): 0–25 s / 0–50 swss.woodward.com

  Trip (tR<<): 0–10 s / 0–20 swss.woodward.com

  Auxiliary Voltage: 19–390 VDC / 36–275 VAC (40–70 Hz)

  Power Consumption: 4 W

  Output Relays: 2 × changeover contacts (alarm/trip)

  Contact Rating: 250 VAC, 1250 VA (ohmic)

  Measuring Circuit: ±24 V, 1 Hz, short‑circuit proof

  Mounting: DIN rail (EN 50022)

  Enclosure: IP40 (front cover, sealable)

  Dimensions (W×H×D): ~70 × 100 × 120 mm

  Weight: ~0.5 kgwss.woodward.com

  Standards: IEC 60255‑1

  Key Features

  Two‑Stage Protection: Separates alarm (high‑R) and trip (low‑R) for graded response.

  Wide Voltage Range: Universal AC/DC power supply (19–390 VDC / 36–275 VAC).

  Adjustable Settings: DIP switches and potentiometers for on‑site calibrationwss.woodward.com.

  Self‑Test: Integrated pushbutton for functional verification.

  Compact & Rugged: DIN‑rail mount, IP40 enclosure, self‑extinguishing casewss.woodward.com.

  No Sampling Needed: Direct connection to rotor circuit; simple installation.

  Applications

  Synchronous Generators: Rotor earth fault protection (power plants, utilities).

  Synchronous Motors: Rotor winding insulation monitoring (industrial drives).

  Brush/Brushless Machines: Compatible with both rotor types.

  Critical Assets: Prevents costly downtime from rotor insulation failure.
