Woodward DTSC-200A Turbine Control Module

Woodward DTSC-200A

Specifications

• Manufacturer: Woodward
• Model: DTSC-200A
• Type: Advanced Turbine & Generator Control / Automatic Transfer Switch (ATS) Controller
• Power Supply: 12/24 VDC (8–35 VDC)Woodward
• Power Consumption: Max 6 W (standby 5 W)Woodward
• Operating Temperature: −25 °C to +70 °CWoodward
• Storage Temperature: −25 °C to +70 °CWoodward
• Humidity: 93% non-condensingWoodward
• Display: 480×272 graphical LCD, tactile buttons
• Communications:
  • USB (service, 1.5 m max)
  • RS-485 (1000 m max)
  • CANopen / CAN bus (120 Ω termination)Woodward
  • Protocols: CANopen, Modbus RTU
• I/O:
  • Configurable discrete I/O; supports expansion (IKD1M)Woodward
  • Analog: Voltage 0–650 VAC, current 5 A isolatedWoodward
• Accuracy: Class 1; frequency 40–85 Hz (±0.1%)
• Dimensions (W×H×D): 237 × 172 × 45 mm
• Weight: ~850 g
• Certifications: CE, UL, CSA, RoHS

Key Features

• FlexApp™ Technology: 3 application modes (ATS, generator, turbine control)
• DynamicsLCD: True-RMS voltage measurement, event logging (300 entries)
• Transfer Modes: Open, delayed, closed transition (<100 ms)
• Generator Protection: Over/under voltage, frequency, reverse power, overload
• Programming: Front panel HMI or USB service tool (Woodward ToolKit™)Woodward
• Multilingual: English, German, Spanish, Polish, RussianWoodward
