WOODWARD DPG-2201-002 Pressure Gauge Controller

Woodward DPG-2201-002 Pressure Gauge Controller (Digital Governor / Engine Speed Controller)







The Woodward DPG-2201-002 is not just a pressure gauge controller. It is a digital programmable speed controller (governor controller) used in diesel/gas engine and generator set control systems.

It regulates engine speed and load control by processing speed feedback signals and controlling an actuator or fuel system.

Key Specifications

• Model: DPG-2201-002
• Brand: Woodward
• Product Type: Digital Speed Controller / Governor Controller
• Function:
  • Engine speed regulation (isochronous / droop control)
  • Load sharing control (generator systems)
  • Signal processing from speed sensors (MPU)
• Power Supply: 9–30 V DC
• Output: Control signal to actuator (fuel system control)
• Interface: 13-terminal industrial connector
• Communication: Serial / configuration interface (model dependent)
• Operating Temperature: approx. -40°C to +85°C
• Control Type: PID-based digital control

What it actually does

This device is the “brain” of engine speed control:

1. Reads speed signal from MPU sensor (e.g. Woodward 1680-631)
2. Compares actual speed vs setpoint
3. Adjusts fuel actuator signal
4. Keeps engine stable under load changes

So it is used in closed-loop control systems.

Features & Advantages

• High-precision engine speed control (±0.25% class regulation)
• Supports isochronous and droop modes
• PID parameter tuning (P / I / D adjustable)
• Fast response to load changes
• Built-in safety fail-safe mode
• Suitable for generator synchronization systems
• Stable operation in harsh industrial environments

Applications

• Diesel generator sets
• Gas generator systems
• Power plants
• Marine engine control systems
• Oil & gas compressors
• Industrial prime movers (engines/turbines)
