Woodward 9907-205 Hand Held Programmer

Product Type: Hand-Held Programmer / Diagnostic Terminal
Part Number: 9907-205
Manufacturer: Woodward
Compatible Systems: Woodward 701A, 723, ProAct, MSLC and DSLC systems

Important: The 9907-205 is not a standalone Speed Control Module. It is a Hand Held Programmer used to configure, adjust, monitor and diagnose compatible Woodward controls. Woodward documentation specifically identifies 9907-205 as the programmer for the 723 control.

Technical Specifications

For 701A applications, the programmer is used to adjust setpoints and continuously monitor control parameters; Woodward documentation states that settings can be stored in nonvolatile memory.

Advantages & Features

• Easy Parameter Configuration: Allows users to adjust control parameters without a PC.
• Real-Time Monitoring: Displays operating parameters for convenient field monitoring.
• Diagnostic Functions: Helps troubleshoot control and I/O-related problems.
• Portable Design: Suitable for commissioning and maintenance work directly at the equipment.
• Serial Communication: Connects directly to the compatible Woodward control.
• Nonvolatile Parameter Storage: For compatible 701A systems, adjusted settings are retained without a battery.
• Wide Compatibility: Used with several legacy Woodward control platforms, depending on the specific application and configuration.

Typical Applications

• Diesel engine speed control
• Gas engine control
• Generator sets
• Turbine and prime-mover systems
• Generator synchronization and load control
• Commissioning and startup
• Field maintenance and troubleshooting
• Industrial power-generation equipment
