WOODWARD 8406-116 EGCP-2 Engine Generator Control

Key Technical Specifications

• EGCP-2 Engine Generator Control for generator-set applications

• 9–32 VDC control power supply

• 50–150 VAC PT input specific to model 8406-116

• 0–5 A RMS CT input

• Generator frequency measurement from 40–70 Hz

• Magnetic pickup input range 100–15,000 Hz

• 8 discrete inputs

• RS-485 and RS-422 communication interfaces

• Provides speed and voltage bias outputs for engine speed and generator control systems

Advantages & Features

• Integrated engine and generator control functions

• Supports synchronization and load-control functions

• Multiple speed-bias output formats

• Multiple voltage-bias output formats

• Flexible analog and discrete I/O

• Suitable for generator-set and prime-mover control applications

Applications

• Diesel generator sets

• Gas engine generator sets

• Engine-generator synchronization

• Load sharing and load control

• Generator protection and monitoring

• Prime mover speed and excitation control

Precautions

• 8406-116 is an EGCP-2 Engine Generator Control, not simply a speed-control module.

• Verify the PT input requirement of 50–150 VAC before installation; 8406-115 uses a different 150–300 VAC PT range.

• Use a compatible 9–32 VDC control power supply.

• Verify CT and PT wiring before energizing the controller.

• The EGCP-2 is specified for non-hazardous locations in the Woodward documentation.
