WOODWARD 5484-803 Speed Controller

WOODWARD 5484-803 Speed Controller / Governor Motor

The Woodward 5484-803 is a 24V DC governor motor / speed control actuator used in industrial engine speed regulation systems, especially in diesel engine governors and generator control systems.

Basic Information

• Part Number: 5484-803
• Brand: Woodward
• Type: Governor Motor / Speed Control Actuator
• Function: Provides mechanical actuation for engine speed regulation

Technical Specifications

• Operating Voltage: 24 VDC
• Speed: approx. 4 RPM (low-speed precision actuator)
• Type: PM (Permanent Magnet) motor / governor drive motor
• Application: Mechanical linkage control for fuel rack or governor system
• Duty: Continuous industrial duty operation
• Construction: Heavy-duty sealed industrial motor assembly

Key Features

• High-torque low-speed actuator design
• Stable and precise engine speed adjustment
• Suitable for continuous operation in harsh environments
• Strong reliability in marine and power generation systems
• Compatible with Woodward governor assemblies
• Designed for accurate fuel control positioning

Application Areas

• Diesel engine speed governor systems
• Generator sets (genset control systems)
• Marine propulsion systems
• Industrial prime movers
• Oil & gas auxiliary engines
• Power plant auxiliary control systems

System Role (Important)

This motor is typically used inside a Woodward mechanical/electro-hydraulic governor system, where it:

• Adjusts fuel rack or control linkage
• Maintains constant engine speed under load changes
• Works with governor control logic or actuator system
• Provides precise mechanical positioning feedback control

Advantages

• High reliability for continuous industrial operation
• Precise low-speed control (stable governor response)
• Strong torque output at low RPM
• Proven use in marine and generator systems worldwide
• Durable construction for vibration and harsh environments

Precautions

• Must be installed in compatible Woodward governor system
• Do not apply incorrect voltage (24VDC only)
• Ensure proper mechanical alignment with linkage system
• Avoid dry running without load connection
• Check gearbox condition if integrated in assembly
