TELEMECANIQUE ZCKJ1D Limit Switch Head

Product Description

TELEMECANIQUE ZCKJ1D is an XC Standard Series Limit Switch Body / Switching Head Assembly designed for industrial position detection applications. It is used with XCKJ series limit switches for detecting the position, movement, or travel limit of mechanical equipment. The unit features snap-action contacts, 1NC + 1NO contact configuration, and M12 connector connection for reliable industrial control applications.

Note: ZCKJ1D is commonly described as a limit switch head, but according to Telemecanique documentation it is classified as a limit switch body (ZCKJ) compatible with XCKJ limit switch assemblies.

Specifications

• Brand: TELEMECANIQUE / Schneider Electric
• Model: ZCKJ1D
• Series: XC Standard
• Product Type: Limit Switch Body / Limit Switch Head
• Compatible Series: XCKJ
• Body Material: Metal
• Contact Configuration: 1NC + 1NO
• Contact Operation: Snap action
• Contact Material: Silver plated contacts
• Electrical Connection: M12 male connector, 5 pins
• Rated Operational Current:
  • 3 A at 240 V AC (AC-15)
  • 0.27 A at 250 V DC (DC-13)
• Rated Thermal Current: 10 A
• Rated Insulation Voltage: 300 V
• Protection Rating: IP66
• Impact Protection: IK07
• Terminal Arrangement:
  • 11-12: NC
  • 13-14: NO
  • 21-22: NC
  • 23-24: NO

Advantages & Features

• High reliability for industrial position detection
• Snap-action mechanism provides fast and stable switching
• Metal housing suitable for harsh industrial environments
• IP66 protection against dust and water ingress
• M12 connector design simplifies installation and maintenance
• Compatible with various XCKJ actuator heads
• Suitable for machine safety and automation applications

Applications

• Industrial machinery position monitoring
• Conveyor systems
• Machine tools
• Packaging equipment
• Material handling systems
• Automated production lines
• Safety interlock applications
• Mechanical travel limit detection

Notes

• Confirm compatibility with the correct XCKJ limit switch actuator head before installation
• Check M12 connector wiring before replacement
• Ensure contact rating matches the connected load
• Avoid exceeding rated current and voltage
• Disconnect power before installation or maintenance
• Verify mechanical mounting position and actuator direction
