SCHNEIDER TBUP357-1A20-AB00 Terminal Block Module

Product Description

SCHNEIDER TBUP357-1A20-AB00 is a SCADAPack 357 Smart Remote Terminal Unit (RTU) Controller Assembly from Control Microsystems (now Schneider Electric). Although the name contains “TBUP”, this model is not a simple terminal block module; it represents a configured SCADAPack 357 RTU system, including the controller and integrated I/O functions.

It is designed for industrial remote monitoring, telemetry, and control applications, commonly used in water treatment, oil & gas, power distribution, and infrastructure automation systems.

Specifications

• Brand: SCHNEIDER ELECTRIC / Control Microsystems
• Model: TBUP357-1A20-AB00
• Product Type: Smart Remote Terminal Unit (RTU) / Controller Module
• Series: SCADAPack 357
• Controller: 32-bit embedded controller
• Integrated I/O Module: 5606 I/O module
• Communication Protocol: Modbus protocol support
• Analog Inputs: Up to 13 channels (depending on configuration)
• Digital Inputs: 32 channels
• Digital Outputs: 16 channels
• Analog Outputs: Optional configuration available
• Expansion: Supports 5000 series I/O modules (up to 20 modules)
• Power Supply: 11–30 V DC
• Mounting: Industrial enclosure / panel mounting
• Application: Remote monitoring and control systems

Advantages & Features

• Integrated RTU solution for remote automation applications
• Supports distributed control and telemetry functions
• Flexible I/O expansion capability
• Supports industrial communication protocols
• Suitable for harsh industrial environments
• Provides reliable data acquisition and remote control
• Reduces the need for additional PLC hardware
• Designed for long-term unattended operation

Applications

• SCADA remote terminal systems
• Water and wastewater treatment
• Oil & gas pipeline monitoring
• Power distribution automation
• Remote pump stations
• Industrial telemetry systems
• Utility infrastructure monitoring
• Process automation systems

Notes

• Confirm exact I/O configuration before replacement
• Check communication protocol settings before commissioning
• Verify DC power supply range (11–30V DC)
• Backup existing RTU program before replacement
• Ensure compatibility with SCADAPack engineering software
• This product is a complete RTU/controller assembly, not only a terminal block
