TELEMECANIQUE ZCKE67 Limit Switch Body

Product Description

TELEMECANIQUE ZCKE67 is an XC Standard Series Limit Switch Head (Switch Body Head) designed for industrial position detection applications. It features a reinforced metal roller plunger actuator and is compatible with XCKJ series limit switch bodies. It is mainly used for detecting mechanical movement, travel limits, and positioning status in automation equipment.

Specifications

• Brand: TELEMECANIQUE / Schneider Electric
• Model: ZCKE67
• Series: XC Standard
• Product Type: Limit Switch Head / Actuator Head
• Device Short Name: ZCKE
• Compatible Switch Body: XCKJ series
• Head Type: Plunger head
• Actuator Type: Reinforced steel roller plunger with spring return
• Operating Movement: Linear movement
• Approach Type: Lateral approach, 2 directions
• Actuation Method: 30° cam operation
• Head Material: Metal
• Mechanical Operation: Positive opening function
• Environment: Standard industrial environment
• Individual Weight: Approx. 0.158 kg

Advantages & Features

• Rugged metal construction for industrial environments
• Reinforced roller plunger design improves mechanical durability
• Reliable position detection and switching operation
• Compatible with Telemecanique XCKJ limit switch systems
• Easy replacement and maintenance
• Suitable for high-frequency mechanical operation
• Supports flexible actuator configurations for automation equipment

Applications

• Industrial machinery position detection
• Conveyor systems
• Machine tools
• Packaging equipment
• Material handling systems
• Automated production lines
• Mechanical travel limit monitoring
• Safety interlock applications

Notes

• ZCKE67 is the limit switch head component, not a complete limit switch assembly
• Must be installed with a compatible XCKJ switch body
• Confirm actuator direction and mechanical mounting position before replacement
• Check electrical switch body specifications separately
• Disconnect power before maintenance
• Ensure proper mechanical alignment to avoid premature wear
