- SIEMENS HFD63F250 Molded Case Circuit Breaker

  Overview

  HFD63F250 belongs to Siemens Sentron series FD frame high interrupting capacity molded case circuit breaker (MCCB), bolt-on mounting type, 3-pole 250A thermal-magnetic trip breaker, widely used in North American industrial three-phase power distribution cabinets for main circuit and branch overload/short-circuit protection. It complies with UL489 and IEC60947-2 standards, features ultra-high short-circuit breaking capacity for heavy industrial loads.

  Key Specifications

  Electrical Parameters

  Poles: 3P three-phase

  Rated current: 250A frame

  Rated voltage: 600V AC / 500V DC

  Breaking capacity (AIC):

  65kA @ 480V AC

  25kA @ 600V AC

  Up to 100kA @ 240V AC

  Trip unit: Thermal-magnetic LI (long-time inverse time overload + instantaneous short-circuit protection), adjustable thermal & magnetic thresholds

  Connection: Line & load side lug terminal (TA1FD350A lugs optional)

  Wire range: Copper 6AWG–350KCM; Aluminum 4AWG–350KCM

  Operating temperature: Max 40°C rated ambient

  Mechanical & Structure

  Mounting method: Bolt-on fixed installation

  Overall dimension (W×H×D): 114mm × 241mm × 102mm (4.5 × 9.5 × 4 inch)

  Frame series: FD high breaking HFD series

  Protection grade: IP20 (cabinet internal use only)

  Expandable accessories: Auxiliary contact, alarm switch, shunt trip, undervoltage trip module

  Certification & Origin

  Certifications: UL Listed, cULus, CE, RoHS compliant

  Origin: Mexico

  Main Functions

  Dual thermal-magnetic comprehensive protection

  Thermal long delay: Protect cables, transformers, motors from continuous overload; adjustable setting for matching load rated current

  Magnetic instantaneous trip: Instant cut-off during short-circuit fault to avoid fire and equipment burnout

  High short-circuit isolation performance

  Ultra-high breaking capacity handles heavy short-circuit current in industrial power distribution systems, prevents arc flash damage in distribution cabinets

  Modular expandable auxiliary signal

  Optional auxiliary switch/alarm contact outputs fault signal to PLC/HMI for remote monitoring and fault alarm notification

  Universal power distribution control

  Serves as main incoming breaker or large motor feeder protection for three-phase industrial equipment

  Clear fault indication

  Built-in trip flag, visually distinguish manual switch-off and fault trip status for quick maintenance judgment

  Advantages

  Ultra-high 65kA breaking capacity at 480V, suitable for large factory power distribution with high short-circuit current

  Adjustable thermal-magnetic trip adapts to transformers, large pumps, fans and motor loads

  Bolt-on stable mounting structure resists vibration in heavy machinery workshops

  Large-capacity lug terminals support thick copper/aluminum cables for high-current power transmission

  Complete optional accessories realize remote tripping and fault signal feedback for intelligent power management

  Standard Sentron series unified size, convenient cabinet layout and spare part replacement
