SIEMENS 6ES7590-1AB60-0AA0 Mounting Rail Accessory

Overview

Key Specifications

• Model: 6ES7590-1AB60-0AA0
• Applicable series: SIMATIC S7-1500 PLC
• Overall dimensions: L160 mm × H155 mm × D16 mm
• Material: Galvanized aluminum alloy, thickness 3 mm
• Weight: Approx. 310 g
• Mounting hole spacing: Central 140 mm for cabinet panel installation
• Standard accessories: Built-in grounding screw for equipotential shielding
• Protection grade: IP20 (only used inside control cabinet)
• Operating temperature: -20 °C ~ +60 °C
• Compliance: CE, RoHS, UL certified
• Origin: Germany

Main Functions

1. Main mechanical mounting platform

   Lock all S7-1500 series PLC modules (CPU, SM signal modules, CM communication modules, TM technology modules) via the dedicated upper profile rail, forming the complete PLC backplane assembly.
2. Integrated auxiliary DIN rail

   The lower side comes with standard 35 mm DIN rail, independently mounting small auxiliary components: miniature relays, circuit breakers, terminal blocks, signal isolators without extra separate rails.
3. System grounding & EMC shielding

   Equipped with dedicated grounding screw to connect cabinet protective earth, unify the ground potential of all PLC modules, suppress electromagnetic interference from inverters and servo drives.
4. Modular cabinet layout

   Short 160 mm size suits small-scale S7-1500 stations with few I/O modules, compact design saves cabinet internal space compared to long-length rails.
5. Rigid shock-resistant structure

   Thick aluminum profile resists vibration in workshop environments, prevents module loosening during long-term equipment operation.

Advantages

• Dual-track integrated design (PLC main rail + auxiliary DIN rail) simplifies cabinet layout and reduces accessory costs
• Complete grounding structure optimizes EMC performance for motion control systems
• Compact 160 mm short size matches small automation stations, avoids redundant empty rail space
• Galvanized aluminum material anti-rust and durable for long-term 24/7 continuous operation
• Standard mounting hole layout for quick panel installation in all standard control cabinets
• Full compatibility with all S7-1500 series CPUs and expansion modules
