SIEMENS 6ES7135-6HD00-0BA1 Analog Output Module

Overview

Key Specifications

• Channel quantity: 4 independent analog output channels
• Supported signal types: 0–10 V voltage, 0/4–20 mA current
• Resolution: 16-bit with sign
• Matching base unit: Type A0 screw terminal base
• Module width: 15 mm, DIN rail mounting, IP20 cabinet use only
• Operating temperature: -30 °C ~ +60 °C (horizontal installation)
• Channel diagnosis: Short-circuit, overload, wire break detection
• Support hot swap without powering off the whole ET200SP station
• Output load capacity:
  • Voltage output: Min. 1 kΩ load resistance
  • Current output: Max. 500 Ω load resistance

Main Functions

1. Convert digital control values from PLC into continuous analog signals to adjust field executing devices.
2. Drive proportional valves, frequency converters, electric regulating actuators, light dimmers and variable-flow pumps.
3. Independent parameter configuration per channel: signal type, output range, smoothing filter and fault substitute value.
4. Real-time upload channel fault alarms such as short circuit and open circuit to PLC and HMI for fast troubleshooting.
5. Output predefined safe substitute values automatically when PROFINET communication fails to avoid equipment risk.

Advantages

• Slim 15 mm narrow design saves cabinet wiring space
• Dual voltage/current universal output reduces spare part types
• High output precision ensures stable closed-loop process control
• Full channel-level fault diagnosis shortens maintenance downtime
• Unified configuration and programming in TIA Portal
• Wide temperature range adapts to harsh industrial workshop environments
