Product Description
Siemens 6ES7532-5NB00-0AB0 is a SIMATIC S7-1500 SM 532 Analog Output Module (AQ 2xU/I ST) designed for precise analog signal output in industrial automation systems. It provides 2-channel voltage/current analog outputs with 16-bit resolution, allowing PLC systems to control drives, valves, actuators, and other analog devices.

Technical Parameters

• Brand: Siemens
• Model: 6ES7532-5NB00-0AB0
• Product Type: Analog Output Module (AQ)
• Series: SIMATIC S7-1500 / SM 532
• Analog Outputs: 2 channels
• Output Type: Voltage / Current output
• Resolution: 16-bit
• Accuracy: ±0.3% of output range
• Voltage Output Range:
  • 0…10 V
  • 1…5 V
  • -10…+10 V
• Current Output Range:
  • 0…20 mA
  • 4…20 mA
  • -20…+20 mA
• Conversion Time: Approx. 0.5 ms per channel
• Output Diagnostics: Supported
• Substitute Value Function: Supported
• Supply Voltage: 24 V DC
• Mounting: S7-1500 rack installation
• Connection: Push-in front connector included
• Protection Degree: IP20

Advantages & Features

• Original Siemens SIMATIC S7-1500 analog output module
• High 16-bit resolution for accurate signal control
• Supports both voltage and current output modes
• Fast signal conversion for real-time industrial control
• Integrated diagnostics improve troubleshooting efficiency
• Supports safety-related shutdown functions up to SIL2 (with suitable configuration)
• Compact modular design for space-saving installation

Applications

• Industrial automation systems
• Motor speed control
• Frequency converter control
• Valve and actuator regulation
• Process control systems
• Production line equipment
• Siemens S7-1500 PLC cabinets

Notes

• Confirm compatibility with the S7-1500 CPU and hardware configuration before installation.
• Check output signal type (0-10V / 4-20mA) before wiring.
• Use shielded cables for stable analog signal transmission.
• Ensure correct parameter configuration in TIA Portal.
