Siemens 6ES7153-2BA02-0XB0 ET200 Interface Module

Product Overview

The Siemens 6ES7153-2BA02-0XB0 is a SIMATIC DP ET 200M IM 153-2 High Feature Interface Module used as the communication interface between a PROFIBUS DP master system and ET 200M distributed I/O modules. It allows S7-300 signal modules and function modules to be used as remote I/O stations in industrial automation networks.

This module supports up to 12 S7-300 I/O modules, redundancy capability, time stamping, isochronous mode, HART auxiliary variables, and 64-channel module operation, making it suitable for advanced industrial automation applications.

Main Specifications

• Manufacturer: Siemens
• Model: 6ES7153-2BA02-0XB0
• Series: SIMATIC DP / ET 200M
• Product Type:
  • ET 200M Interface Module
  • PROFIBUS DP Remote I/O Communication Module
  • IM 153-2 High Feature
• Communication Interface:
  • PROFIBUS DP (RS485)
• Compatible System:
  • SIMATIC S7-300 modules
  • ET 200M distributed I/O system

Technical Specifications

Communication

• Bus System: PROFIBUS DP
• Transmission Speed: Up to 12 Mbit/s
• Interface: RS485
• Station Type: DP Slave
• Supported Functions:
  • DP V0 / DP V1 communication
  • Isochronous operation
  • Time synchronization and timestamping
  • Redundant operation

Module Capacity

• Maximum I/O Modules Supported: 12 × S7-300 modules
• Supports:
  • Digital input modules
  • Digital output modules
  • Analog input/output modules
  • Function modules
  • HART modules
  • 64-channel modules

Electrical Specifications

• Supply Voltage: 24 V DC
• Permissible Voltage Range: 20.4–28.8 V DC
• Current Consumption: Max. approx. 600 mA
• Power Loss: Approx. 5.5 W
• Protection: Reverse polarity protection

Mechanical Specifications

• Dimensions (W × H × D):
  • Approx. 40 × 125 × 117 mm
• Weight: Approx. 360 g
• Mounting:
  • S7-300 rail mounting
• Protection Rating:
  • IP20

Features & Advantages

• Original Siemens SIMATIC ET 200M interface module
• Enables distributed I/O communication over PROFIBUS DP
• Supports high-speed industrial fieldbus communication
• Supports redundant configurations for high availability systems
• Provides precise signal timestamping
• Supports advanced process automation applications
• Compatible with Siemens S7-300 signal modules
• Reduces PLC cabinet wiring complexity

Applications

Used in:

• Factory automation systems
• Process control systems
• Chemical and pharmaceutical plants
• Power industry automation
• Manufacturing production lines
• Large distributed control systems

Typical applications:

• Remote I/O stations
• Motor and drive control
• Sensor/actuator data acquisition
• Process instrumentation systems
