Siemens 6AV6646-1AD22-0AX0 SIMATIC HMI Panel

Product Overview

The Siemens 6AV6646-1AD22-0AX0 is a SIMATIC ITC 2200 Industrial Thin Client designed for industrial visualization and operator interface applications. It features a 22-inch widescreen TFT touch display and supports remote visualization protocols including RDP, VNC, SmartServer, and Web.

Unlike traditional standalone HMI panels, the ITC 2200 operates as an industrial thin client terminal, allowing users to access centralized visualization systems, SCADA servers, industrial PCs, and remote HMI applications.

Main Specifications

• Manufacturer: Siemens
• Model: 6AV6646-1AD22-0AX0
• Series: SIMATIC ITC 2200
• Product Type:
  • Industrial Thin Client
  • HMI Touch Panel
  • Industrial Operator Terminal
• Display Size: 21.5 inch / 22 inch widescreen TFT
• Touch Function: Yes
• Display Type: TFT with LED backlight
• Supported Protocols:
  • RDP
  • VNC
  • SmartServer
  • Web

Display Specifications

• Screen Size: 21.5 inch
• Resolution: 1920 × 1080 pixels (Full HD)
• Display Format: Widescreen
• Colors: 16.7 million colors
• Brightness: Approx. 250 cd/m²
• Backlight Type: LED
• Backlight Lifetime: Approx. 30,000 h at 25 °C
• Touch Screen: Single-touch operation

Mechanical Specifications

• Front Panel Material: Aluminum
• Mounting Type: Panel mounting
• Front Dimensions:
  • Approx. 560 × 380 mm
• Mounting Cutout:
  • Approx. 542 × 362 mm
• Installation Depth: Approx. 75 mm
• Weight: Approx. 7.1 kg

Communication Functions

Supports:

• Remote desktop visualization
• Industrial Ethernet communication
• Remote HMI access
• SCADA client applications
• Web-based visualization

Compatible communication environments:

• Siemens WinCC systems
• Industrial PCs
• SCADA servers
• Automation visualization systems

Features & Advantages

• Original Siemens SIMATIC industrial visualization terminal
• Large 22-inch Full HD touch display
• Suitable for centralized HMI architectures
• Reduces local application maintenance requirements
• Supports multiple remote visualization protocols
• Industrial-grade design for harsh environments
• High visibility and intuitive operator interaction
• Suitable for large equipment monitoring and control

Applications

Used in:

• Factory automation systems
• Production line monitoring
• Process control systems
• Machine operation stations
• SCADA visualization terminals
• Manufacturing plants
• Energy and infrastructure systems

Typical applications:

• Operator control stations
• Remote monitoring terminals
• Centralized HMI access points
• Industrial information display systems
