                                                                                                                                                                                                                                                                                                                                    Product Overview

                                                                                                                                                                                                                                                                                                                                    The SIEMENS 6ES7135-6GB00-0BA1 is a SIMATIC ET 200SP AQ 2xI ST standard analog output module with 2 current outputs. It supports 0–20 mA, 4–20 mA, and ±20 mA output ranges, with up to 16-bit resolution. Siemens lists it as an active ET 200SP analog output module compatible with BU type A0 and A1.

                                                                                                                                                                                                                                                                                                                                    Key Technical Specifications

                                                                                                                                                                                                                                                                                                                                    Item	Specification
                                                                                                                                                                                                                                                                                                                                    Brand	SIEMENS
                                                                                                                                                                                                                                                                                                                                    Model	6ES7135-6GB00-0BA1
                                                                                                                                                                                                                                                                                                                                    Product Family	SIMATIC ET 200SP
                                                                                                                                                                                                                                                                                                                                    Product Type	Analog Output Module
                                                                                                                                                                                                                                                                                                                                    Module Type	AQ 2xI ST
                                                                                                                                                                                                                                                                                                                                    Number of Outputs	2
                                                                                                                                                                                                                                                                                                                                    Output Type	Current
                                                                                                                                                                                                                                                                                                                                    Output Ranges	0–20 mA / 4–20 mA / ±20 mA
                                                                                                                                                                                                                                                                                                                                    Resolution	15-bit / 14-bit / 16-bit incl. sign
                                                                                                                                                                                                                                                                                                                                    Rated Supply Voltage	24 VDC
                                                                                                                                                                                                                                                                                                                                    Permissible Supply Range	19.2–28.8 VDC
                                                                                                                                                                                                                                                                                                                                    Max. Current Consumption	110 mA
                                                                                                                                                                                                                                                                                                                                    Typical Power Loss	1.5 W
                                                                                                                                                                                                                                                                                                                                    Max. Load Resistance	500 Ω
                                                                                                                                                                                                                                                                                                                                    Min. Cycle Time	1 ms
                                                                                                                                                                                                                                                                                                                                    Actuator Connection	2-wire
                                                                                                                                                                                                                                                                                                                                    Diagnostics	Module, supply voltage, wire-break, overflow/underflow
                                                                                                                                                                                                                                                                                                                                    Substitute Values	Supported
                                                                                                                                                                                                                                                                                                                                    BaseUnits	BU Type A0, A1
                                                                                                                                                                                                                                                                                                                                    Communication	ET 200SP backplane bus
                                                                                                                                                                                                                                                                                                                                    STEP 7 / TIA Portal	Supported
                                                                                                                                                                                                                                                                                                                                    Dimensions (W × H × D)	15 × 73 × 58 mm
                                                                                                                                                                                                                                                                                                                                    Approx. Weight	31 g
                                                                                                                                                                                                                                                                                                                                    Operating Temperature	-30 to +60 °C horizontal; -30 to +50 °C vertical

                                                                                                                                                                                                                                                                                                                                    The module provides electrical isolation between the channels and the backplane/electronics supply, while the two analog output channels themselves are not galvanically isolated from each other.

                                                                                                                                                                                                                                                                                                                                    Advantages & Features

                                                                                                                                                                                                                                                                                                                                    • 2-channel analog current output
                                                                                                                                                                                                                                                                                                                                    • Supports 4–20 mA for common industrial instrumentation
                                                                                                                                                                                                                                                                                                                                    • Supports 0–20 mA and ±20 mA ranges
                                                                                                                                                                                                                                                                                                                                    • Up to 16-bit resolution
                                                                                                                                                                                                                                                                                                                                    • Fast minimum cycle time of 1 ms
                                                                                                                                                                                                                                                                                                                                    • Wire-break and limit monitoring
                                                                                                                                                                                                                                                                                                                                    • Configurable substitute values
                                                                                                                                                                                                                                                                                                                                    • Compact 15 mm ET 200SP design
                                                                                                                                                                                                                                                                                                                                    • Supports configuration through TIA Portal
                                                                                                                                                                                                                                                                                                                                    • Active Siemens product with current documentation

                                                                                                                                                                                                                                                                                                                                    Typical Applications

                                                                                                                                                                                                                                                                                                                                    • Process control
                                                                                                                                                                                                                                                                                                                                    • Valve and actuator control
                                                                                                                                                                                                                                                                                                                                    • Industrial instrumentation
                                                                                                                                                                                                                                                                                                                                    • Pressure, flow and temperature control
                                                                                                                                                                                                                                                                                                                                    • Motor speed reference
                                                                                                                                                                                                                                                                                                                                    • Factory automation
                                                                                                                                                                                                                                                                                                                                    • Distributed ET 200SP I/O systems
                                                                                                                                                                                                                                                                                                                                    • PLC-based analog control systems

.The structure and details of the product：
