SIEMENS 6ES7132-6GD51-0BA0 SIMATIC ET 200SP Digital Output Module

Item NO.:
6ES7132-6GD51-0BA0
Market Price:
$500
Product Origin:
Germany
Color:
NEW
Product weight:
0.01KG
Lead Time:
In stock

SIEMENS 6ES7132-6GD51-0BA0 SIMATIC ET 200SP Digital Output Module

Product Overview

The SIEMENS 6ES7132-6GD51-0BA0 is a SIMATIC ET 200SP RQ 4x24VDC/2A ST signal relay digital output module. It provides 4 isolated relay changeover outputs, with a maximum switching current of 2 A per channel. It is designed for ET 200SP BaseUnit type A0.

Key Technical Specifications

Item	Specification
Brand	SIEMENS
Model	6ES7132-6GD51-0BA0
Product Family	SIMATIC ET 200SP
Product Type	Digital Output / Signal Relay Module
Module Designation	RQ 4x24VDC/2A ST
Number of Outputs	4
Output Type	Relay
Contact Configuration	4 × Changeover (CO)
Rated Supply Voltage	24 VDC
Supply Voltage Range	19.2–28.8 VDC
Max. Current per Output	2 A
Max. Total Output Current	8 A, subject to temperature/mounting derating
Max. Switching Frequency	2 Hz, resistive load
Short-Circuit Protection	No
Isolation	Galvanically isolated relay contacts
Compatible BaseUnit	BU Type A0
Color Code	CC00
Current Consumption	50 mA
Typical Power Loss	1.2 W
Dimensions (W × H × D)	15 × 73 × 58 mm
Approx. Weight	30 g
Engineering	STEP 7 / TIA Portal
TIA Portal	V14 or later

Siemens specifies 4 relay outputs, 24 VDC coil supply, and up to 2 A per relay contact. The module also provides supply-voltage and module diagnostics.

Advantages & Features

4 independent relay outputs
Changeover contacts provide flexible switching
Up to 2 A per channel
24 VDC control supply
Galvanically isolated relay contacts
Compact 15 mm ET 200SP design
Module and supply-voltage diagnostics
Supports substitute-value output
Suitable for switching different types of industrial loads

Typical Applications

Industrial automation
PLC output control
Motor and actuator control
Solenoid and valve control
Contactors and relays
Machine automation
Packaging and production equipment
Distributed ET 200SP I/O systems

Important Precautions

This is a relay output module, not a transistor digital output module.
Requires an ET 200SP BU Type A0 BaseUnit.
The relay contacts have no electronic short-circuit protection.
Observe the maximum 2 A per output rating and temperature-dependent total-current derating.
Check the load type and switching frequency before installation.
Verify the exact MLFB and BaseUnit configuration before ordering.
