Siemens 6AV2124-0QC02-0AX0 HMI Panel (TP1500 Comfort)



5

The Siemens 6AV2124-0QC02-0AX0 is a SIMATIC HMI TP1500 Comfort Panel designed for advanced industrial visualization and machine operation control. It provides a large 15-inch widescreen touch display and is widely used in complex automation systems, production lines, and process control environments.

It belongs to Siemens Comfort Panel series, offering high performance, multi-protocol communication, and strong integration with Siemens PLC systems.

Key Specifications

• Model: 6AV2124-0QC02-0AX0
• Series: SIMATIC HMI Comfort Panel
• Type: TP1500 Comfort
• Display: 15.4” TFT widescreen
• Resolution: 1280 × 800 pixels
• Colors: 16.7 million colors
• Touch Type: Analog resistive touchscreen
• Communication: PROFINET, MPI, PROFIBUS DP
• USB Interfaces: Yes (for data/backup devices)
• Operating System: Windows CE 6.0
• Configuration Software: WinCC Comfort (TIA Portal V11 SP2 and above)
• Power Supply: 24 V DC (19.2–28.8 V range)
• Power Consumption: ~20–36 W (typical)
• Protection: Front IP65
• Installation: Panel mounting

Features & Advantages

• Large 15” high-resolution industrial touchscreen
• Stable and reliable HMI performance for 24/7 operation
• Multi-protocol communication (PROFINET / PROFIBUS / MPI)
• Strong integration with Siemens S7-1200 / S7-300 / S7-400 PLCs
• Supports alarms, recipes, trends, and data logging
• Industrial-grade design with IP65 front protection
• Easy configuration via TIA Portal / WinCC Comfort
• High brightness and long backlight lifetime (~80,000 hours)

Applications

• Industrial automation systems
• Machine control panels
• Production line monitoring
• Power plants and energy systems
• Oil & gas and chemical process control
• Water treatment systems
• Packaging and manufacturing machinery

Precautions

• Use only compatible WinCC Comfort versions in TIA Portal
• Ensure stable 24 V DC power supply
• Do not power off during firmware or project download
• Proper grounding required to avoid communication issues
• Protect touchscreen from sharp tools and heavy impact
• Verify correct panel image version when replacing or updating
