SIEMENS 5WG1125-1AB23 KNX Power Supply Module

Item NO.:
5WG1125-1AB23
Market Price:
$500
Product Origin:
Germany
Color:
NEW
Product weight:
0.01KG
Lead Time:
In stock

- - - - SIEMENS 5WG1125-1AB23 KNX Power Supply Module

        Product Overview

        Brand: SIEMENS
        Model: 5WG1125-1AB23
        Product Type: KNX Power Supply Module
        Series: GAMMA instabus KNX
        Type Designation: N 125/23
        Application: KNX Building Automation Power Supply

        The SIEMENS 5WG1125-1AB23 is a KNX power supply unit (N 125/23) designed to provide power for KNX bus devices in building automation systems. It supplies 640 mA output current and includes an integrated bus choke for separating KNX power and communication signals.

        Technical Specifications

        General Data

        Brand: SIEMENS

        Model: 5WG1125-1AB23

        Product Name: N 125/23 KNX Power Supply

        Series: GAMMA instabus KNX

        Type: KNX Bus Power Supply

        Output Current: 640 mA

        Communication System: KNX TP (Twisted Pair)

        Mounting: DIN rail mounting

        Protection Class: IP20

        Installation: Electrical distribution cabinets / automation panels

        Electrical Specifications

        Input Power

        Input Voltage: AC 120…230 V

        Frequency: 50/60 Hz

        KNX Output

        Bus Voltage: DC 29 V (nominal)

        Output Current: 640 mA

        Bus Line Supply: Choked KNX output

        Additional Output: Unchoked auxiliary DC output

        KNX Interface

        KNX Bus Connection

        The module provides:

        KNX bus power supply

        Communication signal decoupling

        KNX line voltage stabilization

        Bus reset function

        Suitable for:

        KNX sensors

        KNX actuators

        KNX room controllers

        KNX touch panels

        Building automation devices

        Protection Functions

        Built-in protection features:

        Short-circuit protection

        Overload protection

        Voltage regulation

        Thermal protection

        LED indicators provide status information:

        Normal operation

        Overload condition

        Short circuit indication

        Mechanical Specifications

        Mounting Type: DIN rail (TH35)

        Width: Approx. 3 modular units

        Dimensions: Approx. 72 × 55 × 90 mm

        Weight: Approx. 0.221 kg

        Protection Rating: IP20

        Features & Advantages

        High Current KNX Supply

        Provides up to 640 mA, suitable for larger KNX bus installations.

        Integrated Bus Choke

        Separates DC power supply and KNX communication signals for stable operation.

        Reliable Siemens KNX Technology

        Designed for continuous operation in smart building systems.

        Compact DIN Rail Design

        Saves cabinet space and simplifies installation.

        System Reset Function

        Allows KNX devices on the line to be reset when required.

        Typical Applications

        Smart building systems

        Office automation

        Hotel automation

        Lighting control systems

        HVAC control systems

        Commercial building management

        KNX residential automation

        Compatible Equipment

        Commonly used with:

        Siemens GAMMA instabus KNX devices

        KNX switching actuators

        KNX dimming actuators

        KNX sensors

        KNX room controllers

        Building Management Systems (BMS)

        Installation Precautions

        Confirm AC 120/230 V input voltage before installation.

        Observe KNX bus polarity (+/-).

        Do not short-circuit KNX output terminals.

        Ensure total KNX device current consumption does not exceed 640 mA.

        Install on proper DIN rail inside an electrical cabinet.

        Disconnect mains power before maintenance.
